Section 2 Installation Instructions
Part Number 020005256 5/15 2-15
DI-1522 Pre-Mix
SERVEND RECOMMENDED PLUMBING DI1522 PREMIX
VALVE LOCATIONS
BOTTOM VIEW
INLET LINE LOCATIONS
FOR 5 VALVE UNIT:
LINE 6 IS NOT USED
3/4” NPT
DRAIN PAN
DRAIN
3/4” NPT
COLD PLATE
DRAIN
FOR ASSISTANCE
CALL (812) 246-7000
5009449-0
LINE 6 LINE 5 LINE 4
LINE 6
LINE 5
LINE 4
LINE 3 LINE 2 LINE 1
LINE 3 LINE 2 LINE 1
FOR 4 VALVE UNIT:
LINES 1 & 6 ARE NOT USED
