3. OPERATION
3.1 Operating the analyser (Refer to Figure 2)
The Servomex 2700 control unit has a tactile 8 button keypad
and back lit LCD (2 lines x 16 characters). During normal use
the LCD will display either the default measurement display or
a menu-based screen editor display. A user can toggle between
the menu display and measurement display and access the
menu-based screen editor using the keypad.
The functions of the keys on the keypad are:
MEASURE Returns the analyser to the measurement display.
MENU Activates the top level menu of the screen editor.
QUIT Aborts the current activity returning the screen
editor to the menu level at which the activity was
selected.
ARROWS Arrow keys select the desired option. When
entering numeric information, the left and right
arrow keys are used to move between digits and
the up and down arrow keys are used to change the
value of each digit. The active digit is highlighted by
blinking. The user presses the 'ENTER' key to
indicate that the numeric input is complete and the
data is to be saved. If the 'QUIT' key is pressed then
the data is not saved and the input is aborted.
Measurement display - Scrolls through alarm
and/or fault messages.
ENTER Indicates that the menu selection is to be
processed or that numerical input is complete.
To initiate any menu operation the MENU key should be
pressed. The LCD will then present the top level menu, which in
turn leads on to other menus.
At each menu, the user highlights the desired option using the
arrow keys and then presses ENTER. Blinking is used to
highlight the selected menu option. During any menu operation,
the fundamental measurements are still being made by the
analyser and all relevant outputs, alarms and diagnostics
remain active.
