5. TECHNICAL SPECIFICATION
5.1 Oxygen measurement performance
* whichever is greater
5.2 Combustibles measurement performance
Item Specification
Analogue output ranges 0-1 min. to 0-25% max. O
2
, in
1% steps
Display resolution 0.01% O
2
Accuracy ±1% of reading or 0.1% O
2
*
Response time (T
90
),
unfiltered software
<10 seconds (sensor head only at
300ml/min)
Item Specification
Analogue output ranges 1750702 – 0-500 min. to
0-30000ppm max. COe, in
1ppm steps
Display resolution 1ppm(v) COe
Accuracy ±5% of full scale output range
Response time (T
90
),
unfiltered software.
<20 seconds (sensor head only at
300ml/min)

Servomex 2700 Specifications

General

Technology	Paramagnetic
Measurement Range	0-100% O2
Outputs	4-20 mA, RS232/RS485
Power Supply	24 VDC or 100-240 VAC
Operating Temperature	0 to 50°C (32 to 122°F)
