3.2 View/Configure functions (Refer to Figures 3a & 3b)
The view functions allow the user to interrogate the analyser
diagnostics and examine the alarm and fault history logs. No
password is required to access the view functions. The view
functions are updated dynamically and values may change
while they are being viewed. To access this display, press the
MENU key and then select VIEW. If the DIAGNOSTICS option
is chosen, the diagnostics appear as a scrolling list of values
and associated descriptions. There are up to ten diagnostics
depending on which sensors are fitted.
The ↑ ↓ keys are used to switch between the following
diagnostic measurements:
Software version
Oxygen sensor output voltage in mV
Oxygen sensor temperature in °C
Oxygen high calibration point in mV
Oxygen low calibration point in mV
Combustibles sensor output voltage in mV
Combustibles sensor temperature in °C
Combustibles high calibration point in mV
Combustibles low calibration point in mV
(Negative values are unfiltered and will differ from those
displayed at top level)
Probe head temperature in °C (if connected)
If the HISTORY option is chosen, either the alarm or fault history
logs can be examined. The ↑ ↓ keys are used to scroll through
the list of history entries in chronological order.
The configure function allows the user to modify and view the
analyser settings. These functions are password protected. To
access these functions, press the MENU key, select
CONFIGURE and then enter a password. There are two
passwords that can be entered; a supervisor password
(default - 2700) which gives access to CALIBRATE, VIEW,
SERVICE & SETUP and an operator password (default - 2000)
which gives access to CALIBRATE and VIEW only. Both
passwords are factory set and may be changed if required.
