12
5. Use the arrow keys to define the start date for the first
blowback. The format will be either day/month/year
(DDMMYY) or month/day/year (MMDDYY) as defined in
the setup clock procedure (see Section 3.3.5).
Use the ENTER key to save the value.
6. Use the arrow keys to define the start time for the first
blowback. Use the ENTER key to save the value.
Successive blowback operations will start at the time and
frequency previously set.
3.3.5 Setting up the real time clock and date format
The process for changing the time, date and the date display
format is as follows:
1. Press the MENU key, then select CONFIGURE, enter a
valid password, select SETUP and then UTILITY.
2. Select CLOCK to change the time and date.
3. The current time and date will be shown on the display for 4
seconds before proceeding. Select YES to continue
changing the time/date or NO to return to the utility menu.
4. Use the arrow keys to define the new date. The date will be
specified either as day/month/year (DDMMYY) or
month/day/year (MMDDYY). Press the ENTER key to save
the new date.
5. Use the arrow keys to define the new time. The format is
hours:minutes (HH:MM).
6. Select either DDMMYY or MMDDYY to specify if dates are
to be displayed in day/month/year or month/day/year
format.
7. The new time and date will be displayed in the selected
format for 4 seconds before returning to the utility menu.
NOTE
After completion of the BLOWBACK process, if FREEZE
has also been selected the analogue outputs remain at
freeze and display shows ‘flushing’ for a fixed period of
120 seconds.

Servomex 2700 Specifications

General

Technology	Paramagnetic
Measurement Range	0-100% O2
Outputs	4-20 mA, RS232/RS485
Power Supply	24 VDC or 100-240 VAC
Operating Temperature	0 to 50°C (32 to 122°F)
