Servomex 2700 User Manual

Servomex 2700 Quickstart Manual
Servomex 2700 Quickstart Manual
2
1.3 Key to Figures on inside of front cover of this manual
(Figures 3a and 3b can be found at the end of this manual)
CE Marking
The Servomex 2700 analyser carries the CE mark which
indicates conformity with the European Community
Directives on CE Marking (93/68/EEC), Electromagnetic
Compatibility (EMC 89/336/EEC) and Low Voltage Directive
(LVD 73/23/EEC).
Servomex 2700 control units are marked in conformity with
the Explosive Atmospheres (ATEX) Directive (94/9/EC)
when fitted with a European hazardous area certification
marking plate.
Figure 1 Sensor head and control unit
1 Terminal box 6 Control unit
2 Sensor head 7 Wall mounting straps
3 4" mounting flange 8 Display and keypad
4 Sample probe 9 Hinged access door
5 Sample filter
Figure 2 Control unit display and keypad layout
1 LCD with measurement display 5 MEASURE key
2 ENTER key 6 QUIT key
3 ARROW keys 7 Alternative main
menu display
4 MENU key
NOTES
As good practice it is recommended that the analyser is
checked/validated with check gas every month and then
calibrated as required. This period can be extended as a
result of operating experience.

Servomex 2700 Specifications

General

Technology	Paramagnetic
Measurement Range	0-100% O2
Outputs	4-20 mA, RS232/RS485
Power Supply	24 VDC or 100-240 VAC
Operating Temperature	0 to 50°C (32 to 122°F)
