23
* Item 4 (Probe Support Disc) is required for Items 13 to 16 when
replacing the <700°C filtered probe in a Supported Probe Installation.
Sample Probes continued on next page.
29 Band Heater - 240Vac 2653-1832
30 4" Mounting Gasket Kit S2720985
31 4" Weld-On Flange Mounting Kit S2720984
32 Mains Protection Cover S2720983
33 Enclosure Gasket Kit (Control Unit &
Sensor Head)
S2700999
34 Fuse Kit (Control Unit & Sensor Head) S2700998 *
* includes: F1.6A HRC (5 x 20mm), F2.5A HRC (5 x 20mm),
F3.15A HRC (5 x 20mm) & F6.3A HRC (5 x 20mm)
Item Servomex 2700 Sample Probes -
description
Spare part
number
1 Silicon Carbide Filter Kit S2740998
2 Probe Tube Coupling 2344-2294
3 Probe Shroud S2740996A
4 Probe Support Disc* S2740995
5 Thermal Spacer Flange Kit 02750997
6 High Temperature Standoff 02750995
7 Probe Retention Flange Kit 02750998
Item Servomex 2700 Sensor Head -
description
Spare part
number

Servomex 2700 Specifications

General

Technology	Paramagnetic
Measurement Range	0-100% O2
Outputs	4-20 mA, RS232/RS485
Power Supply	24 VDC or 100-240 VAC
Operating Temperature	0 to 50°C (32 to 122°F)
