Servomex SERVO PRO 14440D1 - Sample Condition Requirements

01440D Light Industrial Gas Analyser Service Manual.2.2
2.2 Sample condition requirements
Table 2.1 Requirements for Sample Conditions
Dew Point At least 5°C below ambient temperature.
Temperature Nominally at ambient temperature.
Inlet / Outlet
connections
Note: do not
restrict analyser
vent
01440D1STD
6.4mm (1/4”) OD tube.
01440D1STD +
BPR
01440D1FTX 3.2mm (1/8”) OD tube.
Inlet pressure
01440D1STD 1 to 10psig (7 to 70kPag).
01440D1STD +
BPR
17 to 20psia (120 to 140kPaa).
01440D1FTX Typically 0.3kPag (30mmWG) at 200ml/
min.
Flow Rate
01440D1STD 1 to 6l/min.
01440D1STD +
BPR
1 to 2l/min.
01440D1FTX USER LIMITED to 250ml/min. MAXIMUM.
Particulates
01440D1STD
<3µm (micro meters), an internal,
replaceable, 0.6µm filter is fitted as
standard.
01440D1STD +
BPR
01440D1FTX The user must fit an external filter of
0.6µm.
Condition
01440D1STD
Must not be flammable, toxic or corrosive,
as well as being clean and oil free.
01440D1STD +
BPR
01440D1FTX Must not be corrosive, as well as being
clean and oil free.
