Sesamo PROSWING - Arm Installation Details; Arm Extensions; Unit Dimensions

Dimensions
Arm extensions
ATTENTION: For a correct positionning refer to “arm installation” paragraph.
L=50 mm
L=70 mm
L=90 mm
Fig. 4
L=30 mm
(standard)
Fig. 5
56
130
664
86
94
17
630
17
PROSWING (M)
Operating instruction
