External peripherals connectors - Input
* NO =Normally Open NC =Normally Closed
All the input have to be referred to (COM)
PROSWING(M)
Operating instruction
24
SIGNAL
TYPE
DEFAULT*
DESCRIPTION FUNCTION
KEY NC Lock contact. Lock devices can be
connected such as electronic key,
key selector, proximity reader, etc.
If the contact opens the unit sends a complete closing
cycle command (from any position) From this moment
until the signal is closed the door stays closed and no
external peripheral is detected (including the multi-logics
selector). As soon the signal closes the door opens and
allow again the standard operating.
The signal must be short circuited with COM if no devi-
ce is connected.
START 1 NO Opening contact. door opening
devices can be connected.
Closing this signal gives the command to open the door. This
signal is only monitored in 2 Radars logic, selectable through
base or advanced selectors (optionals).
START 2 NO Opening contact. door opening
devices can be connected.
Closing this signal gives the command to open the door. This
signal is monitored both in 2 Radars logic both in 1 Radar
logic selectable through base or advanced selectors (optio-
nals).
SAFE OPEN NC Opening safe contact for safety
sensors monitoring opening cycle.
If the door is opening and the contact closes, the control
board gives a stop command immediately. Opening will only
continue after this signal is disactivated.
The signal must be short circuited with COM if no devi-
ce is connected.
SAFE
CLOSE
NC Closing safe contact for safety sen-
sors monitoring closing cycle.
If the door is closing and the contact opens, the control
board gives an inversion command immediately. Closing will
only continue after this signal is disactivated.
The signal must be short circuited with COM if no devi-
ces (internal or external) are connected.
COM Common electrical contacts.
AUX IN 1/2 NA auxiliary input signal that can be
set as follows:
0 -
DDA opening
Command DDA opening (disabled people).
Opens with motor and closes with spring (LOW ENERGY
mode) with minimal idle time of 5 seconds.
1 -
Emergency open
It opens not depending on the existing logic, over takins as
priority also input KEY. It opens door with priority on all
other contacts.
2
- Inter lock with priority
Opens with priority in case of simultaneous command
3
- Inter lock without priority
It doesn’t open in case of simultaneous command
4 -
Feedback Lock released
Micro switch or contact detecting the status of lock relea-
sed.
5 -
Command lock release
This contact allows to unlock manually the lock without ope-
ning door through motor.
6
- Single command in double
system
In case of Double system, opens only MASTER door.
