Technical specifications
In the diagram there is the max door weights related with the door widths:
Function LOW-ENERGY
PROSWING (M) can be set in the order to meet requirements of Low-Energy application according DIN 18650 or BS 7036-
4.
In Low-Energy mode safety is ensured by:
- low speed;
- reduced dynamic/static force.
ATTENTION: Installation of safety sensors monitoring opening and/or closing path is an option to consider after risk
assessment evaluation.
Power supply 230V +/- 10% ac 50 Hz
Nominal power 85 W
Nominal motor torque 45 Nm
External device power 12Vdc – 12W max
Emergency battery power 24V 1,3 Ah
Opening time 3 ÷ 6 sec (70 °/s ÷ 20 °/s)
Closing time 4 ÷ 15 sec (40 °/s ÷ 10 °/s)
Max opening angle
110°
Wing dimension 700 ÷ 1400 mm
Working temperature Inside automatsm from -10°C to +50°C
Anti-crushing Automatic traction restriction in presence of obstacles
Weight 10,5 kg approx
Service Intensive
PROSWING (M)
Operating instruction
6
