SEW-Eurodrive MOVIDRIVE modular User Manual

3
Configuration
Motor-inverter assignments
Product Manual – MOVIDRIVE
®
modular
120
4-pole DRL.. servomotors/brakemotors for 400V, 50Hz
n
N
Motor type M
N
I
N
BE.. M
B
M
B
m
B
J
Mot_BE
D1 D2
Nm A Nm Nm kg
1)
10
-4
kgm
2
1200 DRL71S4 2.7 1.18 BE05 5 5 11 6.2
DRL71M4 4 1.6 BE1 7 10 12.6 8.4
DRL80S4 6.5 2.15 BE2 10 20 15.2 19.4
DRL80M4 9.5 2.9 BE2 14 20 18.9 26
DRL90L4 15 4.8 BE5 20 40 28.5 49.5
DRL100L4 26 8.5 BE5 40 55 36 74
DRL132S4 42 12.6 BE11 80 110 60 200
DRL132MC4 56 17.6 BE11 110 110 79 355
DRL160M4 85 25.5 BE20 150 200 120 500
DRL160MC4 90 28 BE20 150 200 122 640
DRL180S4 120 34.5 BE30 200 300 162 1030
DRL180M4 135 38 BE30 200 300 183 1250
DRL180L4 165 47 BE30 300 300 194 1440
DRL180LC4 175 52 BE32 400 400 210 1910
DRL200L4 200 58.5 BE32 400 600 315 2590
DRL225S4 250 72 BE32 500 500 350 3160
DRL225MC4 290 89 BE32 600 600 385 4560
1700 DRL71S4 2.7 1.63 BE05 5 5 11 6.2
DRL71M4 4 2.2 BE1 7 10 12.6 8.4
DRL80S4 6.5 2.96 BE2 10 20 15.2 19.4
DRL80M4 9.5 4 BE2 14 20 18.9 26
DRL90L4 15 6.6 BE5 20 40 28.5 49.5
DRL100L4 26 11.4 BE5 40 55 36 74
DRL132S4 42 17.8 BE11 80 110 60 200
DRL132MC4 56 24.9 BE11 110 110 79 355
DRL160M4 85 35 BE20 150 200 120 500
DRL160MC4 90 36 BE20 150 200 122 640
DRL180S4 120 47.5 BE30 200 300 162 1030
DRL180M4 135 52 BE30 200 300 183 1250
DRL180L4 165 63 BE30 300 300 194 1440
DRL180LC4 175 72 BE32 400 400 210 1910
DRL200L4 200 80.6 BE32 400 600 315 2590
DRL225S4 245 97 BE32 500 500 350 3160
DRL225MC4 280 130 BE32 600 600 385 4560
2100 DRL71S4 2.6 2 BE05 5 5 11 6.2
DRL71M4 3.8 2.7 BE1 7 10 12.6 8.4
DRL80S4 6.2 3.59 BE2 10 20 15.2 19.4
DRL80M4 9.5 5 BE2 14 20 18.9 26
DRL90L4 15 8.4 BE5 20 40 28.5 49.5
DRL100L4 25 14 BE5 40 55 36 74
DRL132S4 41 21.4 BE11 80 110 60 200
DRL132MC4 52 28.8 BE11 110 110 79 355
DRL160M4 85 44 BE20 150 200 120 500
DRL160MC4 88 48 BE20 150 200 122 640
DRL180S4 110 55.3 BE30 200 300 162 1030
DRL180M4 130 64 BE30 200 300 183 1250
DRL180L4 160 78 BE30 300 300 194 1440
DRL180LC4 170 87 BE32 400 400 210 1910
DRL200L4 195 99 BE32 400 600 315 2590
DRL225S4 235 119 BE32 500 500 350 3160
DRL225MC4 265 142 BE32 600 600 385 4560
25952676/EN – 01/2020
