3.5.9 Technical data of CMP.. motors
Key to the technical data
n
N
Rated speed
M
0
Standstill torque (thermal continuous torque at low speeds)
I
0
Standstill current
M
pk
Dynamic limit torque
I
max
Maximum permitted motor current
M
0VR
Standstill torque with forced cooling fan
I
0VR
Standstill current with forced cooling fan
J
mot
Mass moment of inertia of the motor
J
bmot
Mass moment of inertia of the brakemotor
M
1m,100°C
Maximum dynamic braking torque in case of emergency off
M
1max
Minimal averaged dynamic braking torque in case of emergency off at
100°C
M
2, 20°C
Nominal torque for slipping brake disk (relative speed between brake disk
and friction surface: 1m/s) at 20°C
M
4,100°C
Minimum holding torque at 100°C
W
max1
Maximum permitted braking work per braking operation
W
max2
Maximum permitted braking work per braking operation with optional bra-
king torque
L
1
Inductance between connection phase and star point
R
1
Resistance between connection phase and star point
V
p0
cold Internal voltage at 1000 min
-1
m
mot
Mass of the motor
m
bmot
Mass of the brakemotor
