7
Device structure, axis system structure
MOVIDRIVE® modular type code
Product Manual – MOVIDRIVE
®
modular
253
7.3 MOVIDRIVE
®
modular type code
MOVIDRIVE
® modular
type code
The following type code applies to MOVIDRIVE
®
modular.
Example: MDA90A-0080-503-X-S00
Product family MD
• MD = MOVIDRIVE
®
Device type A
• A = Single-axis module
• C = Capacitor module
• D = Double-axis module
• P = Power supply module with brake chopper
• S = Switched-mode power supply module with AC and DC supply
• M = Master module UHX45A/MDM90A
Series 90
• 90 = Standard design
• 91 = Double-axis module with MOVILINK
®
DDI
Version A
• A = Version status A
Performance class 0080
• MDA: Nominal output current – e.g. 0080 = 8A
• MDD: Nominal output current – e.g. 0020 = 2 × 2A
• MDP: Nominal power – e.g. 0100 = 10kW
• MDC: Nominal capacitance – e.g. 0120 = 11.7mF
Connection voltage 5
• 5 = AC 380 – 500V
EMC variants of the
power section
0
• 0 = Basic interference suppression integrated
Connection type 3
• 3 = 3-phase connection type
• X = Not relevant
Operating mode X
• 4 = 4-quadrant operation (with brake chopper)
• X = Not relevant
Device variant 0
• 0 = Not relevant
• S = Control MOVI-C
®
CONTROLLER
• C = Power supply module with integrated braking resistor and capacitor
• E = Inverter with device profile CiA402
Designs 00
• 00 = Standard design
Options
• 01 = Axis module MDA90A-0640-.. in size 5
• /X = MOVIDRIVE
®
modular without card slots
• /L = Design with coated printed circuit boards
The following list serves as an example:
• /CES11A = Multi-encoder card
• /CID21A, /CIO21A = I/O expansion card
• /CS..A = Safety card
25952676/EN – 01/2020
