Prefabricated cables
Cables for MOVILINK® DDI
Product Manual – MOVIDRIVE
®
modular
226
4.8.6 Motor cable connection for CM3C.. motors with BK.. brake and MOVILINK
®
DDI interface
Connecting the cable with connectors on the motor end.
The following table shows the core assignment of the cables:
Motor side
Inverter side
Contact
Signal
Core
color
Conductor
color
IEC60757
Identi-
fication
Assembly Description
M23 M40
U U U Black BK U/L1 Not prefabricated Motor connection phase U
V V V Black BK V/L2 Not prefabricated Motor connection phase V
W W W Black BK W/L3 Not prefabricated Motor connection phase
W
A 1 Brake - Yellow YE A Not prefabricated Brake connection -
B + Reserved Orange Upper limit B Not prefabricated Do not connect
C N Reserved Pink PK C Not prefabricated Do not connect
D 2 Brake + Violet VT D Not prefabricated Brake connection +
PE PE PE Yellow/
green
YE/GN Not prefabricated PE connection
DDI DDI DDI Violet VT Coaxial connector MOVILINK
®
DDI
Insulate each unconnected conductor end.
