3
Unit structure
Drive unit MOVIGEAR® performance
Operating Instructions – MOVIGEAR
®
performance
15
3 Unit structure
3.1 Drive unit MOVIGEAR
®
performance
Drive unit
MOVIGEAR
®
performanc
e
MOVIGEAR
®
performance drive units are made up of the 3 core components gear
unit, motor, and drive electronics. These 3 core components are included in one die-
cast aluminum housing (see following figure).
MGF..4-..-C/XT
MGF..4-..-C
MGF..2-..-C
[3]
[4]
[1]
[6]
[5]
[2]
[3]
[4]
[1]
[6]
[5]
[3]
[4]
[1]
[6]
[5]
[2]
[2]
18014423836553739
[1] Electronics cover
[2] Option /PE (pressure compensation fitting electronics)
[3] Gear unit cover
[4] Output shaft variant (pictured here: hollow shaft with keyway)
[5] Optional safety cover
[6] Connection box for cable glands
25945475/EN – 04/2019
