Page #322 background image
11
Technical data and dimension sheets
Mounting kit for braking resistor BW...-.../..C
Operating Instructions – MOVIGEAR
®
performance
322
11.5.2 Technical data
Type BW100-
001/.../...
BW100-
002/.../...
Nominal continuous power at T
amb
~40°C 100W 200W
Resistance value R
BW
100Ω ±10% 100Ω ±10%
Design Flat design
Connections 3 x AWG 20
l = 150cm
Degree of protection (EN60529) IP66
Operating temperature range -25°C to +40°C
Type of cooling Natural convection
Housing temperature at nominal continu-
ous power at T
amb
~40°C
< 300°C
Conformity CE/UL/CSA
Derating at T
U
> 40°C 5% per 10K to 60°C
25945475/EN – 04/2019
