Technical data and dimension sheets
Drive unit with hollow shafts
Operating Instructions – MOVIGEAR
®
performance
356
11.13 Drive unit with hollow shafts
11.13.1 Hollow shaft chamfer
The following figure illustrates the hollow shaft chamfer:
25844033035
The following table shows the dimensions of the chamfer:
Gear unit type Design with hollow shaft (A)
MGFA.1-..-C
1)
2 × 30°
MGFA.2-..-C 2 × 30°
MGFA.4-..-C 2 × 30°
1) Only with MOVIGEAR® classic
