5.9 Plug connectors
5.9.1 Representation of connections
The wiring diagrams of the plug connectors depict the contact end of the connections.
5.9.2 Designation key
The designation of plug connectors is specified according to the following key:
X Terminal
2 Group
1 = Power input
2 = Power output
3 = Encoder
4 = Bus
5 = Inputs and outputs
01 Function
Function of the plug connector within a group
2 Type
Wiring diagram of the plug connector within a function
–
Group number (optional)
for several plug connectors with the same function
Sequence number (optional)
In case of several plug connectors in one group
