7
Fieldbus mode
CANopen
Operating Instructions – MOVITRAC
®
LTP-B
107
7.4.4 Supported transmission modes
The various transmission types can be selected for every process data project (PDO)
in the network management (NMT).
The following transmission types are supported for Rx-PDOs:
Rx PDO transmission mode
Transmission
type
Mode Description
0 – 240 Synchronous The received data are transmitted to the inverter as soon as the next synchronization mes-
sage is received.
254, 255 Asynchronous The received data are transmitted to the inverter without delay.
The following transmission types are supported for Tx PDOs:
Tx PDO transmission mode
Transmission
type
Mode Description
0 Acyclic synchronous Tx PDO is only transmitted if the process data have changed and a SYNC object was re-
ceived.
1 – 240 Cyclic synchronous Tx PDOs are transmitted synchronously and cyclically. The transmission type indicates the
number of the SYNC object required for triggering transmission of the Tx PDO.
254 Asynchronous Tx PDOs are only transmitted when the corresponding Rx PDO has been received.
255 Asynchronous Tx PDOs are always transmitted as soon as the PDO data has changed.
7.4.5 Default allocation plan of process data objects (PDO)
The following table shows the default mapping of the PDOs:
PDO default mapping
Object no. Mapped
object
Length Mapping with default setting Transmission
type
Rx PDO1 1 2001h Unsigned 16 PO1 control word (fixed) 1
2 2002h Integer 16 PO2 (default setting in P5-09 =1; speed setpoint)
3 2003h Unsigned 16 PO3 (default setting in P5-10 =7; no function)
4 2004h Unsigned 16 PO4 (default setting in P5-11 =7; no function)
Tx PDO1 1 2101h Unsigned 16 PI1 status word (fixed) 1
2 2102h Integer 16 PI2 (default setting in P5-12 =1; actual speed)
3 2103h Unsigned 16 PI3 (default setting in P5-13 =2; actual current)
4 2104h Integer 16 PI4 (default setting in P5-14 =4; power)
Rx PDO 2 1 2016h Unsigned 16 Fieldbus analog output 1 1
2 2017h Unsigned 16 Fieldbus analog output 2
3 2015h Unsigned 16 Fieldbus PID reference
4 0006h Unsigned 16 Dummy
Tx PDO2 1 2118h Unsigned 16 Analog input 1 1
2 2119h Integer 16 Analog input 2
3 211Ah Unsigned 16 State of inputs and outputs
4 2116h Unsigned 16 Inverter temperature
INFORMATION
Tx (transmit) and Rx (receive) are depicted from perspective of the slave.
Note: Modified default settings are lost after power off and on again. This means the
settings are restored to default values after power off.
25813137/EN – 08/2018
