SEW-Eurodrive MOVITRAC LTP-B User Manual

5
Startup
User interface
Operating Instructions – MOVITRAC
®
LTP-B
54
5.1.2 Resetting parameters to default settings
The following preconditions must be satisfied for the parameters to be reset to the fac-
tory setting:
• The inverter must not be enabled.
• The inverter must not be in fire mode/emergency mode.
• The display of the inverter must show "Inhibit".
1. Press the 3 keys , , and simultaneously for at least 2sec.
"P-deF" appears on the display.
2. Press the key to acknowledge the "P-deF" message.
5.1.3 Key combinations
Function The device
displays:
Press: Result Example
Quick parameter
group selection
1)
Px-xx <Navigate> + <Up> keys
+
The next higher para-
meter group is selected.
"P1-10" is displayed:
• Press the <Navigate> + <Up> keys.
• Now, "P2-01" is displayed.
Px-xx <Navigate> + <Down> keys
+
The next lower para-
meter group is selected.
"P2-26" is displayed:
• Press the <Navigate> + <Down> keys.
• "P1-01" is now displayed.
Selection of the
lowest group
parameter
Px-xx <Up> + <Down> keys
+
The first parameter of a
group is selected.
"P1-10" is displayed:
• Press the <Up> + <Down> keys.
• "P1-01" is now displayed.
Set the para-
meter to the low-
est value
Numerical
value (when
changing a
parameter
value)
<Up> + <Down> keys
+
The parameter is set to
the lowest value.
When changing P1-01:
• "50.0" is displayed.
• Press the <Up> + <Down> keys.
• "0.0" is now displayed.
Changing indi-
vidual digits of a
parameter value
Numerical
value (when
changing a
parameter
value)
<Stop/reset> + <Navigate>
keys
+
The individual para-
meter digits can be
modified.
When changing P1-10:
• “0” is displayed.
• Press the <Stop/reset> + <Navigate> keys.
• "_0" is now displayed.
• Press the <Up> key.
• "10" is now displayed.
• Press the <Stop/reset> + <Navigate> keys.
• "_10" is now displayed.
• Press the <Up> key.
• "110" is now displayed
etc.
Switching lan-
guages
Select lan-
guage
<Start> and <Up>
+
The desired language
can be selected now.
• English
• German
• French
• Spanish
• Portuguese
• Russian
• Swedish
• Norwegian
• Finnish
Fan and display
test
The complete
display lights
up
Hold all the keys down at the
same time
The display can be
checked for possible
damage.
The function of the fans
can be checked.
This can be checked during maintenance.
1) Parameter group access must be activated: Set P1-14 to "101" or "201".
25813137/EN – 08/2018
