SEW-Eurodrive MOVITRAC LTP-B User Manual

4
Installation
Electrical installation
Operating Instructions – MOVITRAC
®
LTP-B
29
4.4.7 Removing the terminal cover
The front cover of the inverter must be removed to access the terminals of inverters
with degree of protection IP55/IP66. Only use cross-head or slot screwdrivers to open
the terminal cover.
The terminals can be accessed when the marked screws on the front of the product
are removed as shown below.
The front cover is attached by proceeding in reverse order.
Inverters with degree of protection IP66/NEMA 4X
The following inverters have the housing shown below:
Nominal line voltage Power of the inverter
230 V 0.75 – 4kW
400 V 0.75 – 7.5 kW
575 V 0.75 – 11 kW
[1]
9007217412599819
[1] Screws of the front cover
25813137/EN – 08/2018
