19
Contents/Precautions
z
When connecting an external connector device to the
external connection jack, do not put it in obliquely and do
not pull it while it is plugged in.
May cause a malfunction or damage.
z
The handset may become warm during use or charging but
this is not a malfunction. You can keep using it.
z
Do not leave the camera lens in direct sunlight.
May cause discoloration or burn-in of pixels.
z
Use the handset with the nanoSIM/microSD Tray closed.
Liquid such as water (drinking water, sweat, seawater, pet urine, etc.)
or foreign object such as dust may get inside and cause a malfunction.
z
Do not give a strong impact on the fingerprint sensor or
scratch the surface.
May cause not only malfunction of the fingerprint sensor but also
disabling authentication.
z
While using a microSD Card, do not remove the card or turn
off the handset.
May cause data loss or a malfunction.
z
Never place a magnetic card or magnetized items near the
handset.
The data stored in cash cards, credit cards, transport system IC cards,
etc. may be erased.
Putting highly magnetized items closer may cause an error.
z
Do not decorate the handset with films, stickers, etc.
Normal operation may not be possible. For example, each of the
functions that uses the proximity sensor may not work or charging
with the wireless charger may not be possible.
Refer to the following for details on the position of the proximity
sensor.
P. 32 “Part names and functions”
z
The internal battery is not covered by warranty because it is
a consumable product.
Depending on usage, the internal battery may swell as it approaches
the end of its usable life.
Change the battery if its life becomes extremely shorter or the it swells
even after fully charged. For details on replacing the internal battery,
contact the support phone number listed on the Warranty Card.
z
Charge battery in areas where ambient temperature is
between 5° C and 35° C.
z
The battery life depends on the usage and deterioration of
the battery.
z
Do not store the handset under the following situations
because they may lower the performance or shorten the
usable life of the internal battery.
y
Storage with the internal battery fully charged (immediately after
charging is completed)
y
Storage with no battery level (cannot turn the handset on)
Approximately 40% is recommended as the proper battery level for
storage.
z
The following is the type of the internal battery built into the
handset.
Label Battery type
Li-ion00 Lithium-ion
z
The surface of the handset uses the aluminum material.
Note that dent and abrasion are easily remained as
aluminum is a soft material.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sharp Aquos R3 and is the answer not in the manual?

Sharp Aquos R3 Specifications

General IconGeneral
Panel typeIGZO
Screen shapeFlat
Pixel density554 ppi
Display diagonal6.2 \
Touch technologyMulti-touch
Touchscreen typeCapacitive
Display resolution3120 x 1440 pixels
Maximum refresh rate120 Hz
Fingerprint resistantYes
Gorilla Glass versionGorilla Glass 5
Display number of colors16 million colors
High Dynamic Range (HDR) technologyHigh Dynamic Range 10+ (HDR10 Plus)
Processor cores1
Processor familyQualcomm Snapdragon
Coprocessor cores4
Processor frequency2.84 GHz
Coprocessor frequency1.8 GHz
Processor lithography7 nm
Processor architectureARM Cortex-A76
RAM typeLPDDR4X
RAM capacity6 GB
RAM clock speed1866 MHz
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size512 GB
Internal storage capacity128 GB
Flash typeLED
Sensor typeBSI CMOS
ISO sensitivity100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2200, 2250, 2500, 3200
Rear camera typeDual camera
Front camera typeSingle camera
Maximum frame rate30 fps
Video recording modes1080p
Rear camera resolution4608 x 3456 pixels
Rear camera aperture number2.4
Second rear camera pixel size1.4 µm
Rear camera resolution (numeric)20 MP
Front camera resolution (numeric)16 MP
Second rear camera aperture number1.7
Rear camera field of view (FOV) angle78 °
Second rear camera resolution (numeric)12 MP
4G standardLTE-TDD & LTE-FDD
2G standardsEDGE, GPRS, GSM
3G standardsHSPA+, UMTS
SIM card typeNanoSIM
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version5.0
3G bands supported800, 850, 2100 MHz
4G bands supported700, 800, 850, 900, 1700, 1800, 2100, 2300, 2500, 2600 MHz
Bluetooth profilesA2DP, AVRCP, DUN, FTP, HID, HOGP, HSP, OPP, PAN, PBAP, SPP
SIM card capabilityHybrid Dual SIM
2G bands (primary SIM)850, 900, 1900 MHz
2G bands (secondary SIM)850, 900, 1800, 1900 MHz
Mobile network generation4G
Graphics cardAdreno 640
Personal info management (PIM)Alarm clock, Calculator, Calendar, File manager
USB version3.2 Gen 1 (3.1 Gen 1)
USB connector typeUSB Type-C
Headphone connectivity3.5 mm
Form factorBar
Product colorBlack
International Protection (IP) codeIPX5, IPX8
Multimedia Messaging Service (MMS)Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
FM radioNo
Audio systemDolby Atmos
Supported video modes240p, 360p, 480i, 480p, 525i, 540p, 576i, 576p, 625i, 720i, 720p, 768p, 960p, 1024p, 1035i, 1080i, 1080p
Audio formats supportedAAC, AAC+, AMR, AMR-NB, AMR-WB, FLAC, MIDI, MP3, OGA, OGG, OPUS, WAV, WMA
Video formats supported3GP, AVI, DIVX, FLV, H.263, H.264, H.265, MKV, MOV, MP4, VP9, WEBM, WMV, XVID
PlatformAndroid
App distribution platformGoogle Play
Operating system installedAndroid 9.0
Talk time (2G)14.5 h
Talk time (3G)30 h
Battery capacity3200 mAh
Standby time (2G)580 h
Standby time (3G)685 h
Standby time (4G)600 h
Weight and Dimensions IconWeight and Dimensions
Depth8.9 mm
Width156 mm
Height74 mm
Weight185 g
