20
Contents/Precautions
Notes about the charger, wireless charger
and USB cable
z
Use the charger and USB cable provided with this handset
for charging.
z
Charge the battery in areas where the ambient temperature
is between 5° C and 35° C.
z
Do not charge the internal battery in the following locations.
y
Areas with high humidity or dust, or in areas exposed to frequent
vibrations
y
Close to household electronic equipment (TVs, radios, etc.)
z
The charger or USB cable may become warm during
charging but this is not a malfunction. You can keep using it.
z
When using an outlet with a feature to prevent the plug from
being removed accidentally, follow the instructions in the
outlet user's guide.
z
Do not subject to strong impacts. Also, do not deform the
charger terminals.
May cause a malfunction.
z
Do not use the wireless charger while it is covered with a
blanket, etc.
z
Do not use the wireless charger with other than the
specified equipment or dedicated AC adapter.
z
Do not place the handset on the wireless charger while the
USB cable is connected to it.
z
Never place a magnetic card or magnetized items near the
wireless charger.
The data stored in cash cards, credit cards, transport system IC cards,
etc. may be erased.
Putting highly magnetized items closer may cause an error.
Notes about nanoSIM Card
z
Do not apply unnecessary force when inserting/removing
the nanoSIM Card.
z
Customer is responsible for malfunctions arising from
inserting nanoSIM Card into a different IC card reader/writer,
etc.
z
Occasionally clean IC area and always keep it.
When using the nanoSIM Card while IC area is not clean, it may not
work properly.
z
Clean only with a soft and dry cloth (such as the type used
for eyeglasses).
z
Back up to the microSD Card, PC, cloud, etc. or keep a
separate memo of data stored on the nanoSIM Card.
SHARP shall not be liable for any loss of content.
z
Do not damage, touch haphazardly or short-circuit the IC.
May cause data loss or a malfunction.
z
Do not drop or otherwise subject the nanoSIM Card to
severe impact.
May cause a malfunction.
z
Never bend the nanoSIM Card or place heavy objects on it.
May cause a malfunction.
z
Do not insert the nanoSIM Card to the handset with a label,
sticker, etc. attached on the card.
May cause a malfunction.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sharp Aquos R3 and is the answer not in the manual?

Sharp Aquos R3 Specifications

General IconGeneral
Panel typeIGZO
Screen shapeFlat
Pixel density554 ppi
Display diagonal6.2 \
Touch technologyMulti-touch
Touchscreen typeCapacitive
Display resolution3120 x 1440 pixels
Maximum refresh rate120 Hz
Fingerprint resistantYes
Gorilla Glass versionGorilla Glass 5
Display number of colors16 million colors
High Dynamic Range (HDR) technologyHigh Dynamic Range 10+ (HDR10 Plus)
Processor cores1
Processor familyQualcomm Snapdragon
Coprocessor cores4
Processor frequency2.84 GHz
Coprocessor frequency1.8 GHz
Processor lithography7 nm
Processor architectureARM Cortex-A76
RAM typeLPDDR4X
RAM capacity6 GB
RAM clock speed1866 MHz
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size512 GB
Internal storage capacity128 GB
Flash typeLED
Sensor typeBSI CMOS
ISO sensitivity100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2200, 2250, 2500, 3200
Rear camera typeDual camera
Front camera typeSingle camera
Maximum frame rate30 fps
Video recording modes1080p
Rear camera resolution4608 x 3456 pixels
Rear camera aperture number2.4
Second rear camera pixel size1.4 µm
Rear camera resolution (numeric)20 MP
Front camera resolution (numeric)16 MP
Second rear camera aperture number1.7
Rear camera field of view (FOV) angle78 °
Second rear camera resolution (numeric)12 MP
4G standardLTE-TDD & LTE-FDD
2G standardsEDGE, GPRS, GSM
3G standardsHSPA+, UMTS
SIM card typeNanoSIM
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version5.0
3G bands supported800, 850, 2100 MHz
4G bands supported700, 800, 850, 900, 1700, 1800, 2100, 2300, 2500, 2600 MHz
Bluetooth profilesA2DP, AVRCP, DUN, FTP, HID, HOGP, HSP, OPP, PAN, PBAP, SPP
SIM card capabilityHybrid Dual SIM
2G bands (primary SIM)850, 900, 1900 MHz
2G bands (secondary SIM)850, 900, 1800, 1900 MHz
Mobile network generation4G
Graphics cardAdreno 640
Personal info management (PIM)Alarm clock, Calculator, Calendar, File manager
USB version3.2 Gen 1 (3.1 Gen 1)
USB connector typeUSB Type-C
Headphone connectivity3.5 mm
Form factorBar
Product colorBlack
International Protection (IP) codeIPX5, IPX8
Multimedia Messaging Service (MMS)Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
FM radioNo
Audio systemDolby Atmos
Supported video modes240p, 360p, 480i, 480p, 525i, 540p, 576i, 576p, 625i, 720i, 720p, 768p, 960p, 1024p, 1035i, 1080i, 1080p
Audio formats supportedAAC, AAC+, AMR, AMR-NB, AMR-WB, FLAC, MIDI, MP3, OGA, OGG, OPUS, WAV, WMA
Video formats supported3GP, AVI, DIVX, FLV, H.263, H.264, H.265, MKV, MOV, MP4, VP9, WEBM, WMV, XVID
PlatformAndroid
App distribution platformGoogle Play
Operating system installedAndroid 9.0
Talk time (2G)14.5 h
Talk time (3G)30 h
Battery capacity3200 mAh
Standby time (2G)580 h
Standby time (3G)685 h
Standby time (4G)600 h
Weight and Dimensions IconWeight and Dimensions
Depth8.9 mm
Width156 mm
Height74 mm
Weight185 g
