Sharp Aquos R3 User Manual

36
Before Using the Handset
Microphone
z
When using functions which support the microphone, do not
cover the hole of the microphone.
Headset
z
Depending on the type of a headset (commercially available), it
may not be available.
Turning power off forcibly
z
You can turn the power off forcibly by pressing
9
for at least 8 seconds. Release your finger after the vibrator is
activated to turn the power off. Note that data, contents you
have set, etc. may be deleted since the power is turned off
forcibly.

SIM Eject Pin
It is used to insert/remove a nanoSIM Card and microSD Card.
For details on using the SIM Eject Pin
☞
P. 27 “Inserting and
removing the nanoSIM/microSD Tray”
nanoSIM Card
A nanoSIM Card is an IC card that records personal
information, such as your phone number.
z
A nanoSIM Card has a security code called PIN code
(
☞
P. 51 “PIN code”).

Inserting nanoSIM Card
z
For details on how to insert and remove the nanoSIM/microSD
Tray, refer to “Inserting and removing the nanoSIM/microSD Tray”
(
☞
P. 27).
z
If you do not insert a microSD Card, you can insert two nanoSIM
Cards.
1
Remove the nanoSIM/microSD Tray from the
handset
2
Put the nanoSIM Card into the nanoSIM/
microSD Tray with the IC side turned down
z
Check the direction of corner cut.
z
Check the direction of the nanoSIM Card and put it securely.
z
Not to let the nanoSIM Card lift up from the card tray. If the
nanoSIM Card does not fit the card tray, may cause a fault.
Notch
IC
sim
1
sim
2
3
Turn the display side up and then insert the
nanoSIM/microSD Tray into the handset

Sharp Aquos R3 Specifications

General

Panel type	IGZO
Screen shape	Flat
Pixel density	554 ppi
Display diagonal	6.2 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	3120 x 1440 pixels
Maximum refresh rate	120 Hz
Fingerprint resistant	Yes
Gorilla Glass version	Gorilla Glass 5
Display number of colors	16 million colors
High Dynamic Range (HDR) technology	High Dynamic Range 10+ (HDR10 Plus)
Processor cores	1
Processor family	Qualcomm Snapdragon
Coprocessor cores	4
Processor frequency	2.84 GHz
Coprocessor frequency	1.8 GHz
Processor lithography	7 nm
Processor architecture	ARM Cortex-A76
RAM type	LPDDR4X
RAM capacity	6 GB
RAM clock speed	1866 MHz
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	512 GB
Internal storage capacity	128 GB
Flash type	LED
Sensor type	BSI CMOS
ISO sensitivity	100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2200, 2250, 2500, 3200
Rear camera type	Dual camera
Front camera type	Single camera
Maximum frame rate	30 fps
Video recording modes	1080p
Rear camera resolution	4608 x 3456 pixels
Rear camera aperture number	2.4
Second rear camera pixel size	1.4 µm
Rear camera resolution (numeric)	20 MP
Front camera resolution (numeric)	16 MP
Second rear camera aperture number	1.7
Rear camera field of view (FOV) angle	78 °
Second rear camera resolution (numeric)	12 MP
4G standard	LTE-TDD & LTE-FDD
2G standards	EDGE, GPRS, GSM
3G standards	HSPA+, UMTS
SIM card type	NanoSIM
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
3G bands supported	800, 850, 2100 MHz
4G bands supported	700, 800, 850, 900, 1700, 1800, 2100, 2300, 2500, 2600 MHz
Bluetooth profiles	A2DP, AVRCP, DUN, FTP, HID, HOGP, HSP, OPP, PAN, PBAP, SPP
SIM card capability	Hybrid Dual SIM
2G bands (primary SIM)	850, 900, 1900 MHz
2G bands (secondary SIM)	850, 900, 1800, 1900 MHz
Mobile network generation	4G
Graphics card	Adreno 640
Personal info management (PIM)	Alarm clock, Calculator, Calendar, File manager
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-C
Headphone connectivity	3.5 mm
Form factor	Bar
Product color	Black
International Protection (IP) code	IPX5, IPX8
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
FM radio	No
Audio system	Dolby Atmos
Supported video modes	240p, 360p, 480i, 480p, 525i, 540p, 576i, 576p, 625i, 720i, 720p, 768p, 960p, 1024p, 1035i, 1080i, 1080p
Audio formats supported	AAC, AAC+, AMR, AMR-NB, AMR-WB, FLAC, MIDI, MP3, OGA, OGG, OPUS, WAV, WMA
Video formats supported	3GP, AVI, DIVX, FLV, H.263, H.264, H.265, MKV, MOV, MP4, VP9, WEBM, WMV, XVID
Platform	Android
App distribution platform	Google Play
Operating system installed	Android 9.0
Talk time (2G)	14.5 h
Talk time (3G)	30 h
Battery capacity	3200 mAh
Standby time (2G)	580 h
Standby time (3G)	685 h
Standby time (4G)	600 h

Weight and Dimensions

Depth	8.9 mm
Width	156 mm
Height	74 mm
Weight	185 g
