Sharp CD-BA3100 User Manual

31
■ Tuner
Frequency range FM: 87.5-108 MHz
AM: 530-1,720 kHz
■ Cassette deck
Frequency response 50-14,000 Hz (Normal tape)
Signal/noise ratio 55 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/playback)
Wow and flutter 0.3 % (WRMS)
■ Speaker
Type 3-way type speaker system
2" (5 cm) Tweeter
5-1/4" (13 cm) Woofer
5-1/4" (13 cm) Subwoofer
Maximum input power (Total) 200 W
Rated input power (Total) 100 W
Impedance 6 ohms
Dimensions Width: 11" (280 mm)
Height: 13" (330 mm)
Depth: 10-11/16" (272 mm)
Weight 10.6 lbs. (4.8 kg)/each
Specifications
■ General
Power source AC 120 V, 60 Hz
Power consumption 164 W
Dimensions Width: 10-1/4" (260 mm)
Height: 13-5/16" (338 mm)
Depth: 14-13/16" (375 mm)
Weight 19.0 lbs (8.6 kg)
■ Amplifier
Output power 100 watts minimum RMS per channel into 6 ohms from
60 Hz to 20 kHz, 10 % total harmonic distortion
Subwoofer : 60 W/ch
(60 Hz - 200 Hz, 6 ohms, 10 % T.H.D.)
Main : 40 W/ch
(200 Hz - 20 kHz, 6 ohms, 10 % T.H.D.)
Output terminals Speakers: 6 ohms
Headphones: 16-50 ohms (recommended; 32 ohms)
Input terminals Video/Auxiliary (audio signal): 500 mV/47 kohms
■ CD player
Type 6-disc multi-play compact disc player
Signal readout Non-contact, 3-beam semiconductor laser pickup
D/A converter 1-bit D/A converter
Frequency response 20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
As part of our policy of continuous improvement, SHARP reserves the right to make
design and specification changes for product improvement without prior notice. The
performance specification figures indicated are nominal values of production units.
There may be some deviations from these values in individual units.
References
– Specifications –
*BA3100_P29_31 00.12.12, 4:44 PM31

Sharp CD-BA3100 Specifications

General

Brand	Sharp
Model	CD-BA3100
Category	Stereo System
Language	English
