LC-40/46/52LE820E, LC-40/46LU820E
3 – 1
LC-40LE820E
Service Manual
CHAPTER 3. DIMENSIONS
[1] DIMENSIONS (LC-40LE820E/LU820E)
993.0
993,0
450.0
450,0
707.0
707,0
300.0
300,0
659.0
659,0
404.0
404,0
48.0
48,0
132.0
132,0
39.0
39,0
124.6
124,6
275.0
275,0
300.0
300,0
503.2
503,2
890.6
890,6
Unit: mm
