LC-40/46/52LE820E, LC-40/46LU820E
3 – 2
[2] DIMENSIONS (LC-46LE820E/LU820E)
1127.0
1127,0
540.0
540,0
785.0
785,0
400.0
400,0
734.0
734,0
444.0
444,0
51.0
51,0
211.0
211,0
39.0
39,0
157.7
157,7
340.0
340,0
400.0
400,0
577.6
577,6
1023.4
1023,4
Unit: mm
