Sharp LC-40LE820E Service Manual

LC-40/46/52LE820E, LC-40/46LU820E
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DKEYDF455FM01 N P MAIN Unit
N DUNTKF494FM02 AP N P R/C, LED Unit
N DUNTKF493FM03 AP N P ICON Unit
N DUNTKF493FM04 AQ N P LOGO Unit
[2] DKEYDF455FM01 (MAIN Unit)
C501 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C502 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C503 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C508 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C510 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C511 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C521 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C522 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C523 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C530 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C531 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C532 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C533 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C538 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C539 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C542 RC-KZA616WJQZY AB J Capacitor 10 10V Ceramic
C543 RC-KZA616WJQZY AB J Capacitor 10 10V Ceramic
C551 VCEASY1CN477MY AD J Capacitor 470 16V Electrolytic
C554 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C555 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C558 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C559 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C560 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C562 RC-KZA616WJQZY AB J Capacitor 10 10V Ceramic
C565 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C566 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C567 VCEASY1EN107MY AC J Capacitor 100 25V Electrolytic
C568 VCEASY1EN107MY AC J Capacitor 100 25V Electrolytic
C573 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C577 RC-KZA616WJQZY AB J Capacitor 10 10V Ceramic
C578 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C579 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C580 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C581 RC-KZA616WJQZY AB J
Capacitor 10 10V Ceramic
C582 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C584 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C586 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C588 VCCCCZ1HH470JY AB J Capacitor 47p 50V Ceramic
C592 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C603 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C604 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C1103 RC-KZA616WJQZY AB J Capacitor 10 10V Ceramic
C1104 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C1105 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1107 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C1109 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1110 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1111 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C1113 VCEASY1CN477MY AD J Capacitor 470 16V Electrolytic
C1115 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C1116 RC-KZA616WJQZY AB J Capacitor 10 10V Ceramic
C1123 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1124 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1125 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C1126 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C1127 RC-KZA616WJQZY AB J Capacitor 10 10V Ceramic
C1128 RC-KZA616WJQZY AB J Capacitor 10 10V Ceramic
C1129 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C1130 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C1131 RC-KZA616WJQZY AB J Capacitor 10 10V Ceramic
C1133 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C1134 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1135 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1136 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1137 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C1138 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C1139 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C1141
RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C1142 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C1143 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C1144 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C1145 RC-KZA616WJQZY AB J Capacitor 10 10V Ceramic
C1146 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C1147 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C1148 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C1149 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1151 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C1152 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C1153 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
