LC-40/46/52LE820E, LC-40/46LU820E
16
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[3] DUNTKF494FM02 (R/C, LED Unit)
C101 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C103 RC-KZA385WJZZY AD J Capacitor 22 6.3V Ceramic
C104 RC-KZA385WJZZY AD J Capacitor 22 6.3V Ceramic
C105 RC-KZA616WJQZY AB J Capacitor 10 10V Ceramic
D104 RH-EXA633WJQZY AA J Zener Diode RKZ5.6B2KG
IC101 VHiGA1S100W-1Y AE J IC GA1A1S100WP
P103 QPLGNA325WJZZY AC J Plug
R106 VRS-CY1JF223JY AA J Resistor 22k 1/16W Metal Oxide
R113 VRS-CY1JF000JY AA J Resistor 0 1/16W Metal Oxide
R120 VRS-CY1JF101JY AA J Resistor 100 1/16W Metal Oxide
RMC101 RRMCUA053WJZZ AE J Remote Receiver
SLD101 PSLDPA076WJFW AD J Shield
[4] DUNTKF493FM03 (ICON Unit)
D203 RH-PXA153WJZZY AF J LED SMLE12WBX7W1
D204 RH-PXA153WJZZY AF J LED SMLE12WBX7W1
P202 QPLGNA336WJZZY N P Plug
R203 VRS-TV1JD131JY N P Resistor 130 1/10W Metal Oxide
R204 VRS-TV1JD131JY N P Resistor 130 1/10W Metal Oxide
[5] DUNTKF493FM04 (LOGO Unit)
D202 RH-PXA153WJZZY AF J LED SMLE12WBX7W1
D203 RH-PXA153WJZZY AF J LED SMLE12WBX7W1
D204 RH-PXA153WJZZY AF J LED SMLE12WBX7W1
P201 QPLGNA337WJZZY AC J Plug
R202 VRS-TV1JD131JY N P Resistor 130 1/10W Metal Oxide
R203 VRS-TV1JD131JY N P Resistor 130 1/10W Metal Oxide
R204 VRS-TV1JD131JY N P Resistor 130 1/10W Metal Oxide
