LC-40/46/52LE820E, LC-40/46LU820E
1 – 1
LC-40LE820E
Service Manual
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
Item LCD COLOUR TV
(40
"
/81.28 cm),
LC-40LE820E/
LC-40LU820E
LCD COLOUR TV
(46"/116.84 cm),
LC-46LE820E/
LC-46LU820E
LCD COLOUR TV
(52"/132.08 cm),
LC-52LE820E
LCD panel Advanced Super View
& BLACK TFT LCD (40
"
/81.28 cm)
Advanced Super View
& BLACK TFT LCD (46
"/116.84 cm)
Advanced Super View
& BLACK TFT LCD (52
"/132.08 cm)
Resolution 1,920 x 1,080 x 4 pixels
Video colour system PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
TV function TV-standard Analogue CCIR (B/G, I, D/K, L/L’)
Digital DVB-T (2K/8K OFDM), DVB-C
Receiving
channel
VHF/UHF
IR A ch-E69 ch (Digital), E2-E69 ch, F2-F10 ch, I21-I69 ch, IR A-IR J ch
CATV
Hyper-band, S1-S41 ch
TV-tuning system Auto Preset 999 ch (non-Nordic [DTV]), Auto Preset 9999 ch (Nordic [DTV]),
Auto Preset 99 ch (ATV), Auto Label, Auto Sort
STEREO/BILINGUAL NICAM/A2
Audio amplifier 10 W x 2/15 W x 1
Speaker (234 mm x 22 mm) x 2/Ø 110 mm
Terminals Antenna
UHF/VHF 75 Din type (analogue & digital)
RS-232C D-Sub 9 pin male connector
EXT 1 SCART (AV input, Y/C input, RGB input, TV output)
EXT 2 RCA pin (AV input/AUDIO L/R)
EXT 3 15 pin mini D-sub
HDMI 1 (EXT 4) HDMI (ARC)
HDMI 2 (EXT 5) HDMI
HDMI 3 (EXT 6) HDMI
HDMI 4 (EXT 7) HDMI
USB USB
ETHERNET (10/100) Home network connector (only the 820 model series)
HDMI 2/EXT 3 AUDIO (L/R) Ø 3.5 mm jack*
1
DIGITAL AUDIO OUTPUT Optical S/PDIF digital audio output
C. I. (Common Interface) EN50221, R206001, CI Plus specification
OUTPUT/Headphones RCA pin (AUDIO R/L)/Ø 3.5 mm jack (audio output)
OSD language Czech, Danish, Dutch, English, Estonian, Finnish, French, German, Greek,
Hungarian, Italian, Latvian, Lithuanian, Norwegian, Polish, Portuguese, Russian,
Slovak, Slovene, Spanish, Swedish, Turkish, Ukrainian
Power requirement
AC 220 - 240 V, 50 Hz
Power consumption (method IEC62087) 127 W (0.2 W standby*
2
) 147 W (0.2 W standby*
2
) 159 W (0.2 W standby*
2
)
Weight 19.5 kg (without stand),
23.5 kg (with stand)
24.5 kg (without stand),
30.0 kg (with stand)
30.0 kg (without stand),
35.0 kg (with stand)
Operating temperature
0°Cto+40°C
The HDMI 2 and EXT 3 terminals can both use the same audio input terminal.
Standby power consumption applies when the TV is set to not receive EPG data.
As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product
improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be
some deviations from these values in individual units.
*1
*2
•
