Sharp LC-40LE820E Service Manual

LC-40/46/52LE820E, LC-40/46LU820E
4
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[3] CABINET PARTS (LC-40LE820E/LU820E)
1 CCABAC522WJ11 BR N P Front Cabinet Ass'y (LC-40LE820E)
1 CCABAC522WJ12 N P Front Cabinet Ass'y (LC-40LU820E)
1-1 Not available - N - Front Cabinet
1-2 Not available - N - R/C Decoration Cover
1-3 Not available - N - Front Decoration
2 CCABBB698WJ11 BQ N P Rear Cabinet Ass'y
2-1 Not available - N - Rear Cabinet
2-2 HiNDPD710WJSA AF N P Terminal Label (Side)
2-3 HiNDPD711WJSA AD N P Terminal Label (Bottom)
2-4 PSPAHC152WJ1Z AA N P Himelon
2-5 PSPAZC461WJZZ AE N P Spacer
2-6 PZETKA549WJKZ N P Insulation Sheet
2-7 PSPAHC159WJZZ N P Himelon
2-8 PSPAHC160WJZZ N P Himelon
2-9 PSPAHC194WJZZ N P Himelon, x4
3 CPNLHA019WE11 N P Glass Front Panel Ass'y
4 GCOVAD696WJ1A AG N P Stand Cover
5 GCOVAD699WJ1A AD N P AC Cord Cover
6 GCOVAD706WJSA AK N P Terminal Angle (Side)
7 GCOVAD707WJSA AH N P Terminal Angle (Bottom)
8 GCOVAD709WJ1A AF N P ECO Switch Cover
9 LANGKC719WJM1 BB N P Stand Angle
10 LANGKC743WJFW AF N P LCD Angle (Bottom-L)
11 LANGKC744WJFW AG N P LCD Angle (Bottom-R)
12 LANGKC745WJFW AF N P LCD Angle (Top-L)
13 LANGKC746WJFW AF N P LCD Angle (Top-R)
14 LANGKC775WJM1 AH N P VESA Angle, x2
15 LHLDKA011WJKZ AC N P AC Cord Band
16 LHLDWA143WJKZ AC J Wire Holder, x5
17 LHLDWA294WJUZ AC J Wire Holder, x2
18 LHLDZA587WJKZ AC J Spacer, x5
19 LX-BZA170WJF9 AB N P Screw (for VESA/Rear Cabinet Ass'y), x4
20 LX-BZA364WJF7 AA N P Screw (for Woofer), x4
21 NSFTZA362WJFW N P
Shaft (for PWB/Angle), x4
22 PCLiCA004WJKZ AC J Nylon Rivet, x2
23 PMLT-A632WJZZ AD N P Gasket
24 PSLDPA113WJZZ N P Shield Tape C
25 PZETKA548WJKZ N P Insulation Sheet (Power)
26 PZETKA556WJKZ AE N P Insulation Sheet (ECO)
!
27 QACCBA099WJPZ AR N P AC Cord (for U.K.)
!
27 QACCKA052WJPZ AN N P AC Cord (except for U.K.)
28 QCNW-K548WJQZ AF N P Connecting Cord (PD)
29 QCNW-K550WJQZ AE N P Connecting Cord (PL)
30 QCNW-K551WJQZ AT N P Connecting Cord (RA)
31 QCNW-K552WJQZ AF N P Connecting Cord (LB)
32 QCNW-K553WJQZ AH N P Connecting Cord (SB)
33 QCNW-K554WJQZ AK N P Connecting Cord (SP)
34 QCNW-K555WJQZ AE N P Connecting Cord (RL)
!
35 QCNW-K556WJQZ AV N P Connecting Cord (AS)
36 QCNW-K576WJQZ AT N P Connecting Cord (LW)
37 QEARZ0057CEFW AB J Earth Spring
38 QEARZA186WJZZ AF N P Conductive Tape, x2
39 RSP-ZA456WJZZ AX N P Speaker (L/R), x2
40 RSP-ZA458WJZZ BA N P Speaker (Woofer)
41 TLABNC117WJZZ AA N P Model Label
42 TLABZC354WJZZ AB N P ECO Label
43 TLABZC554WJZZ N P Pop Label
44 XBPS730P06WS0 AA J Screw (for PWB/Angle/LCD/Cabinet), x39
45 XBPS730P10WS0 AA J Screw (for Panel Angle), x3
46 XBPS830P06WS0 AA J Screw (for Rear Cabinet Ass'y), x13
47 XBPS830P14WS0 AA N P Screw (for Rear Cabinet Ass'y)
48 XEBS840P10000 AF N J Screw (for Speaker), x4
49 PSPAGA888WJZZ N P Spacer, x4
50 PSPAZC492WJKZ N P Spacer, x2
51 PSPAGA889WJKZ N P Spacer, x2
52 PSPAGA891WJKZ N P Spacer, x2
53 PZETKA563WJKZ N P Insulation Sheet (AC)
54 PSPAKA469WJKZ N P Spacer
55 PCUSGA142WJKZ N P Rubber Bush, x2
56 PSPAZC494WJKZ N P Cooling Sheet
