Sharp LC-40LE820E Service Manual

LC-40/46/52LE820E, LC-40/46LU820E
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
C9646 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C9649 RC-KZA383WJZZY AC J Capacitor 10 25V Ceramic
C9650 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C9652 RC-KZA114WJZZY AB J Capacitor 1 25V Ceramic
C9655 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C9656 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C9657 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C9658 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C9662 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C9664 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C9666 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C9667 RC-KZA616WJQZY AB J Capacitor 10 10V Ceramic
D503 RH-EXA629WJQZY N P Zener Diode RKZ3.9B2KG
D504 RH-EXA629WJQZY N P Zener Diode RKZ3.9B2KG
D507 RH-EXA633WJQZY AA J Zener Diode RKZ5.6B2KG
D508 RH-EXA633WJQZY AA J Zener Diode RKZ5.6B2KG
D509 RH-EXA633WJQZY AA J Zener Diode RKZ5.6B2KG
D510 RH-EXA633WJQZY AA J Zener Diode RKZ5.6B2KG
D512 VHD1SS184++-1Y N P Diode 1SS184(T5L,F,T)
D515 RH-EXA633WJQZY AA J Zener Diode RKZ5.6B2KG
D518 RH-EXA637WJQZY N P Zener Diode RKZ8.2B2KG
D519 RH-EXA637WJQZY N P Zener Diode RKZ8.2B2KG
D520 VHPGPFMV51T-1 N P Photo Diode GPFMV51T
D521 RH-EXA641WJQZY AA J Zener Diode RKZ12B2KG
D522 RH-EXA633WJQZY AA J Zener Diode RKZ5.6B2KG
D523 RH-EXA641WJQZY AA J Zener Diode RKZ12B2KG
D524 RH-EXA641WJQZY AA J Zener Diode RKZ12B2KG
D525 RH-EXA633WJQZY AA J Zener Diode RKZ5.6B2KG
D526 RH-EXA641WJQZY AA J Zener Diode RKZ12B2KG
D527 VHD1SS184++-1Y N P Diode 1SS184(T5L,F,T)
D529 VHD1SS184++-1Y N P Diode 1SS184(T5L,F,T)
D530 VHD1SS184++-1Y N P Diode 1SS184(T5L,F,T)
D1501 RH-EXA633WJQZY AA J Zener Diode RKZ5.6B2KG
D1508 VHD1SS184++-1Y N P
Diode 1SS184(T5L,F,T)
D1509 VHD1SS184++-1Y N P Diode 1SS184(T5L,F,T)
D1511 VHD1SS184++-1Y N P Diode 1SS184(T5L,F,T)
D1512 VHD1SS420++-1Y N P Diode 1SS420(TPL3,F)1SS420(TL3,F,T)
D1513 VHD1SS184++-1Y N P Diode 1SS184(T5L,F,T)
D1517 VHD1SS184++-1Y N P Diode 1SS184(T5L,F,T)
D2701 VHD1SS184++-1Y N P Diode 1SS184(T5L,F,T)
D3301 RH-PXA018WJZZY AC J LED GM1HD55200A
D3303 RH-EXA641WJQZY AA J Zener Diode RKZ12B2KG
D3304 VHD1SS226//-1Y AC J Diode 1SS226(T5L,F,T)
D3305 RH-EXA632WJQZY N P Zener Diode RKZ5.1B2KG
D3306 RH-EXA632WJQZY N P Zener Diode RKZ5.1B2KG
D3309 RH-EXA641WJQZY AA J Zener Diode RKZ12B2KG
D3310 RH-EXA629WJQZY N P Zener Diode RKZ3.9B2KG
D3311 VHD1SS226//-1Y AC J Diode 1SS226(T5L,F,T)
D3313 RH-EXA632WJQZY N P Zener Diode RKZ5.1B2KG
D3315 RH-EXA629WJQZY N P Zener Diode RKZ3.9B2KG
D3317 RH-EXA629WJQZY N P Zener Diode RKZ3.9B2KG
D3318 RH-EXA632WJQZY N P Zener Diode RKZ5.1B2KG
D3319 RH-EXA641WJQZY AA J Zener Diode RKZ12B2KG
D3321 VHD1SS226//-1Y AC J Diode 1SS226(T5L,F,T)
D3323 RH-EXA629WJQZY N P Zener Diode RKZ3.9B2KG
D3324 RH-EXA641WJQZY AA J Zener Diode RKZ12B2KG
D3326 RH-EXA641WJQZY AA J Zener Diode RKZ12B2KG
D3329 RH-EXA641WJQZY AA J Zener Diode RKZ12B2KG
D3330 RH-EXA632WJQZY N P Zener Diode RKZ5.1B2KG
D8457 VHD1SS184++-1Y N P Diode 1SS184(T5L,F,T)
D9601 VHDHSU119//-1Y AB J Diode HSU119TRF-E
D9602 RH-EXA633WJQZY AA J Zener Diode RKZ5.6B2KG
D9603 VHDHSU119//-1Y AB J Diode HSU119TRF-E
D9604 VHDHSU119//-1Y AB J Diode HSU119TRF-E
D9605 RH-EXA629WJQZY N P Zener Diode RKZ3.9B2KG
D9606 VHD1SS226//-1Y AC J Diode 1SS226(T5L,F,T)
D9607 VHDHSU119//-1Y AB J Diode HSU119TRF-E
D9608
RH-EXA629WJQZY N P Zener Diode RKZ3.9B2KG
D9609 VHDHSU119//-1Y AB J Diode HSU119TRF-E
E3301 PRDARA879WJFW N P Heat Sink
FB501 RBLN-A074WJZZY AA J Ferrite Bead
FB502 RBLN-A074WJZZY AA J Ferrite Bead
FB503 RBLN-A074WJZZY AA J Ferrite Bead
FB504 RBLN-A042WJZZY AB J Ferrite Bead
FB505 RBLN-A042WJZZY AB J Ferrite Bead
FB506 RBLN-A042WJZZY AB J Ferrite Bead
FB507 RBLN-A042WJZZY AB J Ferrite Bead
FB508 RBLN-A074WJZZY AA J Ferrite Bead
FB511 RBLN-A074WJZZY AA J Ferrite Bead
FB512 RBLN-A074WJZZY AA J Ferrite Bead
FB517 RBLN-A074WJZZY AA J Ferrite Bead
FB518 RBLN-A074WJZZY AA J Ferrite Bead
FB521 RBLN-A074WJZZY AA J Ferrite Bead
FB522 RBLN-A074WJZZY AA J Ferrite Bead
FB523 RBLN-A042WJZZY AB J Ferrite Bead
[2] DKEYDF455FM01 (MAIN Unit)
