Sharp LC-40LE820E Service Manual

LC-40/46/52LE820E, LC-40/46LU820E
8
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
FB9616 RBLN-A074WJZZY AA J Ferrite Bead
FB9617 RBLN-A206WJZZY AA J Ferrite Bead
FB9619 RBLN-A074WJZZY AA J Ferrite Bead
FB9620 RBLN-A074WJZZY AA J Ferrite Bead
FB9621 RBLN-A074WJZZY AA J Ferrite Bead
FB9622 RBLN-A192WJZZY AA J Ferrite Bead
FB9634 RBLN-A074WJZZY AA J Ferrite Bead
FL3301 RFiLNA119WJZZY AC J Filter
FL3302 RFiLNA119WJZZY AC J Filter
FL3303 RFiLNA119WJZZY AC J Filter
FL3304 RFiLNA119WJZZY AC J Filter
FL3501 RFiLNA119WJZZY AC J Filter
FL3502 RFiLNA119WJZZY AC J Filter
FL3503 RFiLNA119WJZZY AC J Filter
FL3504 RFiLNA119WJZZY AC J Filter
FL3505 RFiLNA119WJZZY AC J Filter
FL3506 RFiLNA119WJZZY AC J Filter
IC501 RH-iXD108WJQZS J IC 24LC21AT-I/SN
IC503 VHiT7SET08U1EY AC J IC TC7SET08FU(5L,JF,T
IC504 VHiMM1506XN-1Y AD J IC MM1506XNRE
IC506 VHiM3221EiP-1Y AK J IC MAX3221EIPower
IC1101 VHiTC7W53U/-1Y AF J IC TC7W53FU(TE12L,F)
IC1102 VHiLV4053FT-1Y AE J IC TC74LVX4053FT(EL)
IC1103 VHiTCR5SB25-1Y AD J IC TCR5SB25(TE85L,F)
IC1104 VHiNJ2888F5-1Y AC J IC NJM2888F05(TE1)
IC1106 VHiSTV0297E-1Q N P IC STV0297E
IC1107 VHiS170B50U-1Y N P IC S-1170B50UC-OUJTFG
IC1501 VHiCM123408-1Y AE J IC CM1234-08DE
IC1502 VHiCM123408-1Y AE J IC CM1234-08DE
IC1503 VHiCM123408-1Y AE J IC CM1234-08DE
IC1504 VHiSii9287+-1Q AP J IC SiI9287ACNU
IC1505 VHiAHC1G08W-1Y AD J IC 74AHC1G08GW/G,125
IC1506 VHiCM123408-1Y AE J IC CM1234-08DE
IC1508 VHiLCX04FT+-1Y AD J
IC TC74LCX04FT(EL,K)
IC2001 VHiS80927NM-1Y AC J IC S-80927CNMC-G8XT2G
IC2002 RH-iXC786WJNJQ J IC R5F364A6NFB
IC2004 VHiR24002AS-1Y N P IC R1EX24002ASAS0A
IC2005 VHiLCX125FT-1Y AD J IC TC74LCX125FT(EL,K)
IC2006 VHiTCVHC32T-1Y AE J IC TC74VHC32FT(EL)
IC2007 VHiAHC1G08W-1Y AD J IC 74AHC1G08GW/G,125
IC2008 VHi7WH126FU-1Y AE J IC TC7WH126FU(TE12L,F)
IC2009 VHiTC7SH00U-1Y AC J IC TC7SH00FU(T5L,JF,T
IC2601 VHiHC2G66DP-1Y AD J IC 74HC2G66DP,125
IC2701 VHiYSS951VZ-1Y N P IC YSS951-VZE2
IC2702 VHiYDA164QZ-1Y N P IC YDA164-QZE2
IC2703 VHiYDA164QZ-1Y N P IC YDA164-QZE2
IC3301 VHiS170B50U-1Y N P IC S-1170B50UC-OUJTFG
IC3302 Not Available - N -
IC MT5391DWCJ (Please replace the MAIN PWB when it is necessary to replace this
IC.)
IC3501 RH-iXC754WJQZQ AX J IC H5PS1G63EFR-G7C
IC3502 RH-iXC754WJQZQ AX J IC H5PS1G63EFR-G7C
IC4401 VHiLCX244FT-1Y AE J IC TC74LCX244FT(EL,K)
IC4402 VHiLCX244FT-1Y AE J IC TC74LCX244FT(EL,K)
IC4403 VHiLCX244FT-1Y AE J IC TC74LCX244FT(EL,K)
IC4404 VHiAOZ1320C-1Y AE J IC AOZ1320CI-04
IC4405 VHiMT8295AE-1Q N P IC MT8295AE
IC4410 VHiS170B50U-1Y N P IC S-1170B50UC-OUJTFG
IC8401 Not Available - -
IC K9F1208U0C-PCB0 (Please replace the MAIN PWB when it is necessary to replace
this IC.)
IC8451 VHi7WH126FU-1Y AE J IC TC7WH126FU(TE12L,F)
IC8452 VHiLCX157FT-1Y AD J IC TC74LCX157FT(EKJ)
IC8454 VHiAHC1G08W-1Y AD J IC 74AHC1G08GW/G,125
IC8455 VHiR24064AS-1Y N P IC R1EX24064ASAS0A
IC9501 VHiKSZ8041T-1Y N P IC KSZ8041TLI
IC9601 VHiHC2G66DP-1Y AD J IC 74HC2G66DP,125
IC9603 VHiMM3141YN-1Y AC J IC MM3141YNRE
IC9604 VHiMP2303A+-1Y AF J IC MP2303ADN-LF-Z
IC9605 VHiMP2303A+-1Y AF J IC MP2303ADN-LF-Z
IC9606 VHiMP2303A+-1Y AF J IC MP2303ADN-LF-Z
IC9608 VHiMP2303A+-1Y AF J IC MP2303ADN-LF-Z
IC9609 VHiTC5B33A+-1Y N P IC TCR5SB33A(5LSP1,FT
IC9610 VHiPQ1LAX95-1Y AD J IC PQ1LAX95MSPQ
IC9612 VHiTAR5SB50-1Y AC J IC TAR5SB50(TE85L,F)
J501 QJAKEA073WJZZ AD J Jack
J504 QJAKJ0047CEZZ AD J Jack
J505 QJAKMA002WJZZ AE J Jack
J3301 QSOCZA205WJQZ N P Jack
J9501 QJAKZA081WJQZ N P Jack
L502 VPCEM100MR70NY AC J Coil Peaking 10µH
L504 VPMTN1R8JR54NY N P Coil Peaking 1.8µH
L1102 VPCEM2R2MR23NY AC J Coil Peaking 2.2µH
L1103 VPCEM100MR70NY AC J Coil Peaking 10µH
L1501 RCiLFA228WJZZY AD J Coil
L1502 RCiLFA228WJZZY AD J Coil
L1503 RCiLFA228WJZZY AD J Coil
[2] DKEYDF455FM01 (MAIN Unit)
