LC-40/46/52LE820E, LC-40/46LU820E
6 – 6
14/21
1 FRV-N Firmware Version xxxxx
2 FRC-N Boot Script Version xxxxx
3 FRC-N Device Version xxxxx
4 TCON FPGA1 Serial Flash Version xxxxx
5 TCON FPGA2 Serial Flash Version xxxxx
6 TCON FPGA1 Config Rom Version xxxxx
7 TCON FPGA2 Config Rom Version xxxxx
15/21
1 POWER LED BRIGHTNESS 0
2 MENU LED BRIGHTNESS 0
3 INPUT LED BRIGHTNESS 0
4 CH UP LED BRIGHTNESS 0
5 CH DOWN LED BRIGHTNESS 0
6 VOL UP LED BRIGHTNESS 0
7 VOL DOWN LED BRIGHTNESS 0
8 LOGO LED BRIGHTNESS 99
9 ICON LED BRIGHTNESS 99
10 ICON LED BRIGHTNESS (STANDBY) 30
16/21
1 POWER KEY SENSITIVITY 0
2 MENU KEY SENSITIVITY 0
3 INPUT KEY SENSITIVITY 0
4 CH UP KEY SENSITIVITY 0
5 CH DOWN KEY SENSITIVITY 0
6 VOL UP KEY SENSITIVITY 0
7 VOL DOWN KEY SENSITIVITY 0
17/21
1 KEY STRENGTH GET MODE Enter
2 POWER KEY STRENGTH
3 MENU KEY STRENGTH
INPUT KEY STRENGTH
4 CH UP KEY STRENGTH
5 CH DOWN KEY STRENGTH
6 VOL UP KEY STRENGTH
7 VOL DOWN KEY STRENGTH
18/21
1 READ/WRITE READ Read/Write
2 SLAVE/ADDRESS SLAVE0 Slave address
3 REGISTER ADDRESS 0x 0 Register address
0x 0
4 WRITE DATA 0x 0 Writing data
0x 0
5 READ DATA 0x 0 Reading data
0x 0
19/21
1 RF AGC BG 6 RF-AGC BG adjustment execution
2 RF AGC DK 5 RF-AGC DKG adjustment execution
3 RF AGC I 6 RF-AGC I adjustment execution
4 RF AGC L/L' 4 RF-AGC L/L' adjustment execution
20/21
1 ERROR STANDBY CAUSE 1 NO RECORD ERROR STANDBY CAUSE
2 ERROR STANDBY CAUSE 2 NO RECORD
3 ERROR STANDBY CAUSE 3 NO RECORD
4 ERROR STANDBY CAUSE 4 NO RECORD
5 ERROR STANDBY CAUSE 5 NO RECORD
6 STANDBY CAUSE RESET OFF Reset stand by cause.
Page Line Item Description Remarks (adjustment detail, etc.)
To Next Page
