Sharp LC-40LE820E Service Manual

LC-40/46/52LE820E, LC-40/46LU820E
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[4] CABINET PARTS (LC-46LE820E/LU820E)
1 CCABAC523WJ11 BS N P Front Cabinet Ass'y (LC-46LE820E)
1 CCABAC523WJ12 N P Front Cabinet Ass'y (LC-46LU820E)
1-1 Not available - N - Front Cabinet
1-2 Not available - N - R/C Decoration Cover
1-3 Not available - N - Front Decoration
1-4 PSPAGA907WJZZ N P Spacer
1-5 PSPAZC495WJZZ N P Double Side Tape, x3
2 CCABBB699WJ11 N P Rear Cabinet Ass'y (for U.K.)
2 CCABBB699WE11 N P Rear Cabinet Ass'y (except fot U.K.)
2-1 Not available - N - Rear Cabinet
2-2 HiNDPD710WJSA AF N P Terminal Label (Side)
2-3 HiNDPD711WJSA AD N P Terminal Label (Bottom)
2-4 PSPAHC152WJ1Z AA N P Himelon (except for U.K.)
2-5 PSPAZC461WJZZ AE N P Spacer
2-6 PZETKA542WJKZ BA N P Insulation Sheet
2-7 PSPAHC159WJZZ N P Himelon
2-8 PSPAHC160WJZZ N P Himelon
2-9 PSPAHC194WJZZ N P Himelon, x4
3 CPNLHA020WJ11 N P Glass Front Panel Ass'y
4 GCOVAD697WJ1A AK N P Stand Cover
5 GCOVAD699WJ1A AD N P AC Cord Cover
6 GCOVAD706WJSA AK N P Terminal Angle (Side)
7 GCOVAD707WJSA AH N P Terminal Angle (Bottom)
8 GCOVAD709WJ1A AF N P ECO Switch Cover
9 LANGKC720WJFW AV N P Stand Angle
10 LANGKC743WJFW AF N P LCD Angle (Bottom-L)
11 LANGKC744WJFW AG N P LCD Angle (Bottom-R)
12 LANGKC745WJFW AF N P LCD Angle (Top-L)
13 LANGKC746WJFW AF N P LCD Angle (Top-R)
14 LANGKC747WJFW AE N P LCD Angle (B-C-A)
15 LANGKC811WJFW AD N P LCD Angle (B-C-B)
16 LHLDKA011WJKZ AC N P AC Cord Band
17 LHLDWA143WJKZ AC J Wire Holder, x3
18 LHLDWA176WJUZ AC J
Wire Holder
19 LHLDWA294WJUZ AC J Wire Holder, x7
20 LHLDZA587WJKZ AC J Spacer, x5
21 LX-BZA170WJF9 AB N P Screw (for VESA/Rear Cabinet Ass'y), x4
22 LX-BZA364WJF7 AA N P Screw (for Woofer), x4
23 NSFTZA362WJFW N P Shaft (for PWB/Angle), x4
24 PCLiCA004WJKZ AC J Nylon Rivet, x2
25 PMLT-A632WJZZ AD N P Gasket
26 PSLDPA113WJZZ N P Shield Tape C
27 PZETKA541WJKZ AW N P Insulation Sheet (Power)
28 PZETKA556WJKZ AE N P Insulation Sheet (ECO)
!
29 QACCBA099WJPZ AR N P AC Cord (for U.K.)
!
29 QACCKA052WJPZ AN N P AC Cord (except for U.K.)
30 QCNW-K548WJQZ AF N P Connecting Cord (PD)
31 QCNW-K550WJQZ AE N P Connecting Cord (PL)
32 QCNW-K552WJQZ AF N P Connecting Cord (LB)
!
33 QCNW-K556WJQZ AV N P Connecting Cord (AS)
34 QCNW-K572WJQZ N P Connecting Cord (RA)
35 QCNW-K559WJQZ AK N P Connecting Cord (SP)
36 QCNW-K573WJQZ N P Connecting Cord (RL)
37 QCNW-K570WJQZ AG N P Connecting Cord (SB)
38 QCNW-K561WJQZ N P Connecting Cord (LW)
39 QEARZ0057CEFW AB J Earth Spring
40 QEARZA186WJZZ AF N P Conductive Tape, x2
41 RSP-ZA456WJZZ AX N P Speaker (L/R), x2
42 RSP-ZA458WJZZ BA N P Speaker (Woofer)
43 TLABNC117WJZZ AA N P Model Label
45 TLABZC520WJZZ N P Pop Label
46 XBPS730P06WS0 AA J Screw (for PWB/Angle/LCD/Cabinet), x39
47 XBPS730P10WS0 AA J Screw (for Panel Angle), x5
48 XBPS830P06WS0 AA J Screw (for Rear Cabinet Ass'y), x17
49 XBPS830P14WS0 AA N P Screw (for Rear Cabinet Ass'y)
50 XEBS840P10000 AF N J Screw (for Speaker/Rear Cabinet Ass'y), x4
51 PSPAGA888WJZZ N P Spacer, x4
52 PSPAZC492WJKZ N P Himelon, x2
53 PSPAGA889WJKZ N P Spacer, x2
54 PSPAGA891WJKZ N P Spacer, x2
55 PSPAGA892WJKZ N P Spacer
56 LANGFA776WJFW N P BL Chassis Support Angle
57 PZETKA563WJKZ N P Insulation Sheet (AC)
58 PSPAKA469WJKZ N P Spacer
