Sharp LC-40LE820E Service Manual

LC-40/46/52LE820E, LC-40/46LU820E
8
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[5] CABINET PARTS (LC-52LE820E)
1 CCABAC524WJ31 CH N P Front Cabinet Ass'y
1-1 Not available - N - Front Cabinet
1-2 Not available - N - R/C Decoration Cover
1-3 Not available - N - Front Decoration
2 CCABBB700WE11 N P Rear Cabinet Ass'y
2-1 Not available - N - Rear Cabinet
2-2 HiNDPD710WJSA AF N P Terminal Label (Side)
2-3 HiNDPD711WJSA AD N P Terminal Label (Bottom)
2-4 PSPAHC152WJ1Z AA N P Himelon
2-5 PSPAZC461WJZZ AE N P Spacer
2-6 PZETKA542WJKZ BA N P Insulation Sheet
2-7 PSPAHC159WJZZ N P Himelon
2-8 PSPAHC160WJZZ N P Himelon
2-9 PSPAHC194WJZZ N P Himelon, x4
3 CPNLHA021WJ11 N P Glass Front Panel Ass'y
4 GCOVAD697WJ1A AK N P Stand Cover
5 GCOVAD699WJ1A AD N P AC Cord Cover
6 GCOVAD706WJSA AK N P Terminal Angle (Side)
7 GCOVAD707WJSA AH N P Terminal Angle (Bottom)
8 GCOVAD709WJ1A AF N P ECO Switch Cover
11 LANGKC720WJFW AV N P Stand Angle
12 LANGKC743WJFW AF N P LCD Angle (Bottom-L)
13 LANGKC744WJFW AG N P LCD Angle (Bottom-R)
14 LANGKC745WJFW AF N P LCD Angle (Top-L)
15 LANGKC746WJFW AF N P LCD Angle (Top-R)
16 LANGKC747WJFW AE N P LCD Angle (B-C-A)
17 LANGKC811WJFW AD N P LCD Angle (B-C-B)
18 LHLDKA011WJKZ AC N P AC Cord Band
19 LHLDWA143WJKZ AC J Wire Holder, x6
21 LHLDZA587WJKZ AC J Spacer, x5
22 LX-BZA170WJF9 AB N P Screw (for VESA/Rear Cabinet Ass'y), x4
23 LX-BZA364WJF7 AA N P Screw (for Woofer), x4
24 NSFTZA362WJFW N P Shaft (for PWB/Angle), x4
25 PCLiCA004WJKZ AC J
Nylon Rivet, x2
26 PMLT-A632WJZZ AD N P Gasket
27 PSLDPA113WJZZ N P Shield Tape C
28 PZETKA541WJKZ AW N P Insulation Sheet (Power)
29 PZETKA556WJKZ AE N P Insulation Sheet (ECO)
!
30 QACCBA099WJPZ AR N P AC Cord (for U.K.)
!
30 QACCKA052WJPZ AN N P AC Cord (except for U.K.)
31 QCNW-K548WJQZ AF N P Connecting Cord (PD)
32 QCNW-K550WJQZ AE N P Connecting Cord (PL)
33 QCNW-K552WJQZ AF N P Connecting Cord (LB)
!
34 QCNW-K556WJQZ AV N P Connecting Cord (AS)
35 QCNW-K562WJQZ AV N P Connecting Cord (RA)
36 QCNW-K579WJQZ N P Connecting Cord (SP)
37 QCNW-K574WJQZ N P Connecting Cord (SB)
38 QCNW-K565WJQZ AE N P Connecting Cord (RL)
39 QCNW-K577WJQZ AT N P Connecting Cord (LW)
40 QEARZ0057CEFW AB J Earth Spring
41 QEARZA186WJZZ AF N P Conductive Tape, x2
42 RSP-ZA456WJZZ AX N P Speaker (L/R), x2
43 RSP-ZA457WJZZ BA N P Speaker (Woofer)
44 TLABNC117WJZZ AA N P Model Label
46 TLABZC554WJZZ N P Pop Label
47 XBPS730P06WS0 AA J Screw (for PWB/Angle/LCD Angle/Cabinet), x43
48 XBPS730P10WS0 AA J Screw (for LCD/Front Cabinet Ass'y), x6
49 XBPS830P06WS0 AA J Screw (for Raer Cabinet), x19
50 XBPS830P14WS0 AA N P Screw (for Rear Cabinet)
51 XEBS840P10000 AF N J Screw (for Speaker/Rear Cabinet Ass'y), x4
52 PSPAGA888WJZZ N P Spacer, x4
53 PSPAZC492WJKZ N P Himelon, x2
54 PSPAGA889WJKZ N P Spacer, x2
55 PSPAGA891WJKZ N P Spacer, x2
56 PSPAGA892WJKZ N P Spacer
57 LANGFA776WJFW N P BL Chassis Support Angle, x2
58 PZETKA563WJKZ N P Insulation Sheet (AC)
59 PSPAKA469WJKZ N P Spacer
60 LHLDWA294WJUZ AC J Wire Holder, x8
61 LHLDWA176WJUZ AC J Wire Holder
62 PCUSGA142WJKZ N P Rubber Bush
