LC-40/46/52/60LE810UN (1st Edition)
4 – 17
2. Removing of Speaker-L/R.
1. Remove the 2 lock screws and detach the Stand cover .
2. Disconnect SP wire.
3. Detach the Speaker-L , Speaker-R .
MAIN Unit
[SP]
[SP]
4Speaker-R 3 Speaker-L
2 Stand Cover
1
