5-73
SCANNER/INTERNET FAX
Contents
PREVIEW CHECK SCREEN
This section explains the preview check screen.
(1) Preview image
A preview of the scanned original appears.
If the image is cut off, use the scroll bars at the right and
bottom of the screen to scroll the image. Touch a bar and slide
it to scroll. (You can also touch the keys to scroll.)
(2) Change page keys
When there are multiple pages, use these keys to
change pages.
• keys: Go to the first or the last page.
• keys: Go to the previous page or the next
page.
•
Page number display:
This shows the total number of pages
and the current page number. You can
touch the current page number key and
enter a number with the numeric keys
to go to that page number.
(3) [Sender Info] key
When Internet fax mode is selected, touch to display the
sender information for I-fax own address send.
This key can only be touched when the entire preview
image is displayed in the preview screen.
(4) [Function Rev.] key
Touch to check special mode settings or scan settings for
two-sided originals.
(5) Display zoom key
Use this to set the zoom ratio of the displayed image.
Changes from the left in the order "Full Page", "Twice",
"4 Times", "8 Times". The setting applies to all pages in
the file, not just the displayed page.
(6) "Display Rotation" key
This rotates the image right or left by 90 degrees. The
rotation applies to all pages in the file, not just the
displayed page.
(7) [Start Sending] key
Touch to begin transmission.
Preview
Display Rotation
/0010
0001
Function Rev.
B/W
Start
Sending
Sender Info
(5)
(6)
(7)
(4)
(3)
(2)
(1)
• A preview image is an image for display on the touch panel. It will differ from the actual print result.
• The preview image reflects certain scanning and special mode settings.
Settings reflected in the preview image are as follows:
Scanning settings: Original, Color Mode
Special modes: Erase, Suppress Background, Card Shot, Drop Out Color, Blank Page Skip
To Next Page
