8-7
TROUBLESHOOTING
Contents
PRINTING ON ENVELOPES
The procedure for printing on an envelope is explained below. Only the name and
address side of an envelope can be printed on.
It is recommended that you do a test print to check the print result before using an
envelope.
Type
Size
Fixed Paper Side
Disable Duplex
Paper Property
Bypass
Feeding Approved Job
Disable Staple
Envelope
COM-10
Tray Settings
Copy
Print
Fax I-Fax
Doc. Filing
5
5
Change
Back
1 Place paper in the bypass tray.
Print on the name and address side
Type : Envelope
Size : Select the envelope size
2 Tray Settings.
(1)
(2)
(3)
(4)
3 Select settings in the printer driver.
(1) Select the size of the envelope in "Paper
Size".
(2) Select "Bypass Tray" from "Paper Source"
in "Paper Selection".
(3) Select [Envelope] in "Paper Type".
If needed, select the "Rotate 180 degrees" checkbox ( )
in "Image Orientation" on the [Main] tab.
(4) Click the [OK] button.
To Next Page
