MX-M350/M450 N/U SIMULATION 9 - 59
4) Press [START] key.
(Table 1)
(Table 2)
(Table 3)
When the total of the above set value and 10 is entered, the mode
is changed to the duplex mode (DD), and a duplex copy is made.
Operation/Procedure
(Print image off-center position adjustment)
NOTE: This simulation cannot provide an accurate adjustment. Do
not use.
1) Enter the number corresponding to the number of the paper
feed tray to be adjusted with 10-key. (Select one of 3 - 8.)
Set range 25 - 200 (%)
Item
Set
range
Default
0 TRAY SELECT Paper feed tray
selection
1 - 5 –
1 COPY START Copy START (Default) – –
2 MAGNIFICATION Print magnification
ratio
25 -
200%
–
(Lead edge adjustment value)
3 L4 Distance from the
front surface image
lead edge to the scale
of 10mm (SPF: 200%)
0 - 999 –
4 L5 Distance from the
back surface image
lead edge to the scale
of 10mm (SPF: 200%)
–
(Image loss set value: SIDE 1)
5 LEAD_EDGE Front surface lead
edge image loss set
value
0 - 99 15
6 FRONT_REAR Front surface side
edge image loss set
value
20
7 TRAIL_EDGE Front surface rear
edge image loss set
value
0 - 20 0
(Image loss set value: SIDE 2)
8 LEAD_EDGE Back surface lead
edge image loss set
value
0 - 99 15
9 FRONT/REAR Back surface side
edge image loss set
value
20
10 TRAIL_EDGE Back surface rear
edge image loss set
value
0 - 20 0
Normal display NOW COPYING.
ERROR display Door open DOOR OPEN.
Jam JAM
Paper empty PAPER EMPTY.
1TRAY1 TRAY1
2TRAY2 TRAY2
3TRAY3 TRAY3
4TRAY4 TRAY4
5 BPT Manual feed
Select 2, and
press [START] key.
Press [START] key, or
press [SYSTEM SETTINGS] key.
50-10
Purpose Adjustment
Function
(Purpose)
Used to adjust the print image off-center position.
(Adjusted separately for each paper feed section.)
Item Picture quality Image position
Item Set range Default
0 TRAY SELECT Paper feed tray
selection
1 - 5 –
1 COPY START Copy START (Default) – –
2 MAGNIFICATION Print magnification
ratio
25 - 400% 100
(Off-center adjustment value)
3 TRAY1 Tray 1 adjustment 0 - 99 50
4 TRAY2 Tray 2 adjustment
5 TRAY3 Tray 3 adjustment
6 TRAY4 Tray 4 adjustment
7 BPT Manual feed tray
adjustment
8 ADU Adjustment when
paper is fed again from
ADU
50
1
2
SIMULATION 50-7
LEAD EDGE ADJUSTMENT(SPF CALC.). SELECT 0-10, AND PRESS
START.
0.TRAY SELECT 1 1.COPY START
2.MAGNIFICATION 200
(ADJUSTMENT DATA) 3.L4 160 4.L5 160
(IMAGE LOSS SETTING)
SIDE1: 5.LEAD_EDGE 15 6.FRONT/REAR 20 7.TRAIL_EDGE 0
SIDE2: 8.LEAD_EDGE 15 9.FRONT/REAR 20 10.TRAIL_EDGE 0
Press [SYSTEM SETTINGS] key.
Press [START] key.
Press [SYSTEM SETTINGS] key,
or terminate copying.
Press [START] key or
press [SYSTEM SETTINGS] key.
SIMULATION 50-7
LEAD EDGE ADJUSTMENT(SPF CALC.). INPUT VALUE 0-999, AND
PRESS START.
3.L4
SIMULATION 50-7
LEAD EDGE ADJUSTMENT(SPF CALC.). NOW COPYING.
SIMULATION 50-7
LEAD EDGE ADJUSTMENT(SPF CALC.). SELECT 1-15, AND PRESS
START.
(FEED TRAY)
1.TRAY1 2.TRAY2 3.TRAY3 4.TRAY4
5.BPT
Select 1,
and press
[START] key.
Select 0, and press [START] key.
Select other than 0 - 2, and press [START] key.
100
SIMULATION 50-7
LEAD EDGE ADJUSTMENT(SPF CALC.).
(MAGNIFICATION)
INPUT 25-200(%)
