4. Set value recording sheet
Purpose/kind Section
Contents
Main code Sub code Set value Description
Adjustment Paper feed section 51 2 Adjustment value of contact pressure of the paper on the main
body resist roller
Optical unit 26 8 Adjustment value (lens shift amount adjustment value) of copy
magnification ratio in zoom copying
45 Adjustment value of copy paper lead edge void amount
46 1 Adjustment value of copy density (exposure level) in each copy
mode and of copy density gradient (exposure gradient)
Manual copy mode density level 1 (Not toner save mode)
Manual copy mode density level 5 (Not toner save mode)
Manual copy mode density level 1 (Toner save mode)
Manual copy mode density level 5 (Toner save mode)
Auto copy mode density level 1 (Not toner save mode)
Auto copy mode density level 5 (Not toner save mode)
Auto copy mode density level 1 (Toner save mode)
Auto copy mode density level 5 (Toner save mode)
Photo copy mode density level 1 (Not toner save mode)
Photo copy mode density level 5 (Not toner save mode)
47 The AE sensor and the optical section characteristics memory
data for the change in the copy lamp application voltage
48 1 The vertical copy magnification ratio adjustment value
2 The horizontal copy magnification ratio adjustment value (when
the document table is used)
50 1 The adjustment value of copy image position on the copy
paper
SEt value A
Set value B
Set value C
SPF unit 48 3 The horizontal copy magnification ratio adjustment value
(When the SPF is used)
51 2 The adjustment value of the contact pressure between the SPF
resist roller and the document
6 SPF copy mode density level
Developing unit 25 2 Setting the toner concentration level
Setting Specifications 26 1 Model setting (With SPF or without ?)
6 Destination specifications
Fuser unit 26 13 Setting of the main motor operation mode in warming up
43 1 The set value of fusing temperature
2 Fusing temperature setting in the power save mode
Process 44 1 Image correction mode function setting
Maintenance counter 21 1 Setting of the maintenance cycle
Memorizef•%!alues in theolumn ofxSet valu for ef cient s vicing hen the memory trouble occurs and the EEPROm is replaced.
Make a copy of this sheet and use with the service sheet.
10 – 4
