Sharp UX-40 Service Manual

UX-40DE
FO-50DE
8 – 1
CHAPTER 8. OTHERS
[1] Service tools
1. List
Extension board unit
NO. PARTS CODE DESCRIPTION Q’TY
PRICE
RANK
1 C P W B S 3 0 4 5 S C S 1 Extension board unit (Control PWB) 1AR
2 P S H E Z 3 3 5 4 S C Z Z Shading wave memory standard paper 1AD
1 C C N W – 4 7 5 6 S C 0 1 SPEAKER RELAY CABLE 1AK
2 C C N W – 4 7 5 8 S C 0 1 CIS RELAY CABLE 1AQ
3 C C N W – 4 7 5 9 S C 0 1 HEAD RELAY CABLE 1AX
4 C C N W – 4 7 6 0 S C 0 1 CAM SWITCH RELAY CABLE 1AK
5 C C N W – 4 7 6 1 S C 0 1 FRONT SENSOR RELAY CABLE 1AK
6 C C N W – 4 7 6 3 S C 0 1 MOTOR RELAY CABLE 1AP
7 Q C N W – 4 9 6 9 S C Z Z SENSOR RELAY CABLE 1BF
8 C C N W - 2 7 4 A S C 0 1 PANEL RELAY CABLE 1AU
9 C C N W - 2 7 5 A S C 0 1 DOOR SWITCH RELAY CABLE 1AL
10 C C N W - 2 7 6 A S C 0 1 CUTTER RELAY CABLE 1AH
11 V R S – T S 2 A D 1 0 2 J RESISTOR
(
1/10W 1KΩ ±5%
)[
R145
]
1AA
12 V H P S G 2 0 6 S / / –1 PHOTO TRANSISTOR
[
PI1
]
1AG
13 V H P S G 2 0 6 S / / –1 PHOTO TRANSISTOR
[
PI2
]
1AG
NO. PARTS CODE DESCRIPTION Q’TY
PRICE
RANK
R145
(BOTTOM
SIDE)
C17
PESNS
PI2
DG1
PI1
PSNS
E
C
A
K
A
K
E
C
EXTENSION CONTROL PWB
