Sharp UX-40 Service Manual

NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PA RT
RANK
DESCRIPTION
UX-40DE
FO-50DE
[7] Control PWB unit
241 VRS-TS2AD303J AA C Resistor(1/10W 30KΩ ±5%) [R173]
242 VRSTS2AD1183F AA C Resistor(1/10W 118KΩ ±1%) [R175]
243 VRS-TS2AD473J AA C Resistor(1/10W 47KΩ ±5%) [R176]
244 VRS-TS2AD102J AA C Resistor(1/10W 1.0KΩ ±5%) [R177]
245 VRS-TS2AD104J AA C Resistor(1/10W 100KΩ ±5%) [R178]
246 VRS-TS2AD104J AA C Resistor(1/10W 100KΩ ±5%) [R179]
247 VRS-TS2AD203J AA C Resistor(1/10W 20KΩ ±5%) [R180]
248 VRS-TS2AD562J AA C Resistor(1/10W 5.6KΩ ±5%) [R184]
249 VRS-TS2AD203J AA C Resistor(1/10W 20KΩ ±5%) [R185]
250 VRS-TS2AD201J AG C Resistor(1/10W 200Ω ±5%) [R186]
251 VRS-TS2AD474J AA C Resistor(1/10W 470KΩ ±5%) [R187]
252 VRS-TS2AD000J AA C Resistor(1/10W 0Ω ±5%) [R188]
253 VRS-TS2AD000J AA C Resistor(1/10W 0Ω ±5%) [R189]
254 RR-TZ3018SCZZ AC C Block resistor(470Ωx4) [RA1]
255 RR-TZ3017SCZZ AC C Block resistor(270Ωx4) [RA2]
256 RR-TZ3017SCZZ AC C Block resistor(270Ωx4) [RA3]
257 RR-TZ3018SCZZ AC C Block resistor(470Ωx4) [RA4]
258 RR-TZ3018SCZZ AC C Block resistor(470Ωx4) [RA5]
259 RR-TZ3017SCZZ AC C Block resistor(270Ωx4) [RA6]
260 RR-TZ3017SCZZ AC C Block resistor(270Ωx4) [RA7]
261 RR-TZ3017SCZZ AC C Block resistor(270Ωx4) [RA8]
262 RR-TZ3018SCZZ AC C Block resistor(470Ωx4) [RA9]
263 RR-TZ3018SCZZ AC C Block resistor(470Ωx4) [RA10]
264 RR-TZ3018SCZZ AC C Block resistor(470Ωx4) [RA11]
265 RR-TZ3018SCZZ AC C Block resistor(470Ωx4) [RA12]
266 RR-TZ3017SCZZ AC C Block resistor(270Ωx4) [RA13]
267 RR-TZ3017SCZZ AC C Block resistor(270Ωx4) [RA14]
268 RR-TZ3018SCZZ AC C Block resistor(470Ωx4) [RA15]
269 RR-TZ3018SCZZ AC C Block resistor(470Ωx4) [RA16]
270 VHI62FP332P-1 AF B IC(XC62FP3302P) [REG100]
271 RRLYD3138XHZZ AG B Relay [RY1]
272 RCRSQ2157SCZZ AF B Crystal(32.256MHz) [X1]
273 RCRSB0297AFZZ AD B Crystal(32.768kHz) [X2]
(Unit)
901 CPWBX3084FF01 N E Control PWB unit(Without ROM)
[8] TEL/Liu PWB unit
!
1 VHVRA501PV6-1 AE B Varistor(RA-501P-V6-2) [AR1]
!
2 VHVRA501PV6-1 AE B Varistor(RA-501P-V6-2) [AR2]
3 QCNW-4753XHZZ AE C Cable [ARG]
4 VCQYNA1HM474K AE C Capacitor(50WV 0.47µF) [C1]
5 RC-FZ3053FFZZ N C Capacitor(250WV 1.0µF) [C2]
6 RC-FZ3055FFZZ N C Capacitor(250WV 0.47µF) [C3]
7 VCEAGA1HW106M AA C Capacitor(50WV 10µF) [C4]
8 VCEAGA1HW475M AA C Capacitor(50WV 4.7µF) [C5]
9 VCEAGA1HW226M AB C Capacitor(50WV 22µF) [C6]
10 VCEAGA1HW475M AA C Capacitor(50WV 4.7µF) [C7]
11 VCEAGA1HW106M AA C Capacitor(50WV 10µF) [C8]
12 VCEAGA1HW225M AA C Capacitor(50WV 2.2µF) [C10]
13 VCEAGA1HW226M AB C Capacitor(50WV 22µF) [C11]
14 VCEAGA1EW476M AA C Capacitor(50WV 47µF) [C12]
15 VCEAGA1HW226M AB C Capacitor(50WV 22µF) [C13]
16 VCKYTV1HB103K AB C Capacitor(50WV 0.01µF) [C101]
17 VCKYTV1HB103K AB C Capacitor(50WV 0.01µF) [C102]
18 VCKYTQ1HB223K AB C Capacitor(50WV 0.022µF) [C103]
19 VCKYTQ1HB333K AA C Capacitor(50WV 0.033µF) [C104]
20 VCKYTQ1HB223K AB C Capacitor(50WV 0.022µF) [C105]
21 VCKYTV1HB473K AA C Capacitor(50WV 0.047µF) [C106]
22 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C107]
23 VCKYTV1HF104Z AA C Capacitor(50WV 0.1µF) [C109]
24 VCKYTV1HB222K AA C Capacitor(50WV 2200PF) [C110]
25 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C111]
26 VCKYTQ1HB103K AA C Capacitor(50WV 0.01µF) [C115]
27 VRS-TP2BD000J AA C Resistor(1/8W 0Ω ±5%) [C116]
28 VCKYTQ1HB563K AA C Capacitor(50WV 0.056µF) [C118]
29 VCCCTV1HH101J AA C Capacitor(50WV 100PF) [C119]
30 VCKYTV1HF104Z AA C Capacitor(50WV 0.1µF) [C120]
31 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C121]
32 VCKYTV1HF104Z AA C Capacitor(50WV 0.1µF) [C122]
33 VCKYTV1HB122K AB C Capacitor(50WV 1200PF) [C123]
34 VCKYTV1HF104Z AA C Capacitor(50WV 0.1µF) [C124]
35 VCKYTV1HF104Z AA C Capacitor(50WV 0.1µF) [C125]
36 VCKYTV1HF104Z AA C Capacitor(50WV 0.1µF) [C126]
37 VCKYTV1HB103K AB C Capacitor(50WV 0.01µF) [C127]
!
38 RRLYZ3427SCZZ AN B Relay [CML]
39 QJAKZ2079XH0D AD C Jack [CNHJ]
40 QCNCM2548SC1B AH C Connector(12pin) [CNLIUA]
41 QCNCM2548SC0E N C Connector(5pin) [CNLIUB]
42 QJAKZ2073SCFF AE N C Jack [CNLNJ]
43 QJAKZ2073SCFD AE N C Jack [CNTLJ]
– 10 –
