Sharp UX-40 Service Manual

NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
UX-40DE
FO-50DE
– 11 –
[8] TEL/Liu PWB unit
44 RH-DX0045BMZZ N B Diode(1N4148) [D1]
45 RH-DX0045BMZZ N B Diode(1N4148) [D2]
46 RH-DX0045BMZZ N B Diode(1N4148) [D3]
47 RH-DX0045BMZZ N B Diode(1N4148) [D4]
48 QSW-Z2263XHZZ AG B Hook switch [HOOK SW]
49 VHILMT2904DR2 N B IC(LMT2904DR) [IC101]
50 VHILMT2904DR2 N B IC(LMT2904DR) [IC102]
51 RFILN2027XHZZ AC C Coil(R-5C) [L2A]
52 RFILN2027XHZZ AC C Coil(R-5C) [L2B]
53 RCILF2125SCZZ AD C Coil(4.7mH) [L3]
54 RCILF2125SCZZ AD C Coil(4.7mH) [L5]
!
55 RFILN2027XHZZ AC C Coil(R-5C) [L6]
!
56 RFILN2027XHZZ AC C Coil(R-5C) [L7]
!
57 RFILN2027XHZZ AC C Coil(R-5C) [L8]
!
58 VHPTLP627//-1 AH B Photo coupler(TLP627) [PC2]
!
59 VHPTLP627//-1 AH B Photo coupler(TLP627) [PC3]
!
60 VHPTLP521-1BL AE B Photo coupler(TLP521) [PC5]
!
61 VHPTLP521-1BL AE B Photo coupler(TLP521) [PC6]
62 VS2SA1807-P-1 AE B Transistor(2SA1807) [Q1]
63 VS2N5401///-1 N B Transistor(2N5401) [Q2]
64 VSBS108////-1 AE B FET(BS108) [Q3]
65 VSBC847B///-1 N B Transistor(BC847B) [Q101]
66 VSDPC114EK/-1 N B Transistor(PDTC114) [Q102]
67 VSDPC114EK/-1 N B Transistor(PDTC114) [Q106]
68 VSDPC114EK/-1 N B Transistor(PDTC114) [Q108]
69 VSDPC114EK/-1 N B Transistor(PDTC114) [Q110]
70 VRD-HT2HY473J AA C Resistor(1/2W 47KΩ ±5%) [R2]
71 VRS-HT3LA821J N C Resistor(3W 820Ω ±5%) [R3]
72 VRS-TS2AD161J AA C Resistor(1/10W 160Ω ±5%) [R101]
73 VRS-TS2AD124J AA C Resistor(1/10W 120KΩ ±5%) [R102]
74 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R103]
75 VRS-TP2BD120J N C Resistor(1/8W 12Ω ±5%) [R104]
76 VRS-TS2AD474J AA C Resistor(1/10W 470KΩ ±5%) [R105]
77 VRS-TS2AD203J AA C Resistor(1/10W 20KΩ ±5%) [R107]
78 VRS-TP2BD560J AA C Resistor(1/8W 56Ω ±5%) [R108]
79 VRS-TS2AD000J AA C Resistor(1/10W 0Ω ±5%) [R109]
80 VRS-TP2BD150J AA C Resistor(1/8W 15Ω ±5%) [R110]
81 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R111]
82 VRS-TP2BD470J AA C Resistor(1/8W 47Ω ±5%) [R112]
83 VRS-TS2AD152J AA C Resistor(1/10W 1.5KΩ ±5%) [R114]
84 VRS-TS2AD102J AA C Resistor(1/10W 1KΩ ±5%) [R115]
85 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R116]
86 VRS-TS2AD163J AA C Resistor(1/10W 16KΩ ±5%) [R117]
87 VRS-TS2AD203J AA C Resistor(1/10W 20KΩ ±5%) [R118]
88 VRS-TS2AD151J AA C Resistor(1/10W 150Ω ±5%) [R119]
89 VRS-TS2AD102J AA C Resistor(1/10W 1KΩ ±5%) [R120]
90 VRS-TS2AD303J AA C Resistor(1/10W 30KΩ ±5%) [R121]
91 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R122]
92 VRS-TS2AD332J AA C Resistor(1/10W 3.3KΩ ±5%) [R123]
93 VRS-TS2AD473J AA C Resistor(1/10W 47KΩ ±5%) [R124]
94 VRS-TS2AD243J AA C Resistor(1/10W 24KΩ ±5%) [R125]
95 VRS-TS2AD102J AA C Resistor(1/10W 1KΩ ±5%) [R126]
96 VRS-TS2AD822J AA C Resistor(1/10W 8.2KΩ ±5%) [R128]
97 VRS-TS2AD332J AA C Resistor(1/10W 3.3KΩ ±5%) [R129]
98 VRS-TS2AD222J AA C Resistor(1/10W 2.2KΩ ±5%) [R131]
99 VRS-TS2AD391J AA C Resistor(1/10W 390Ω ±5%) [R133]
100 VRS-TS2AD000J AA C Resistor(1/10W 0Ω ±5%) [R134]
101 VRS-TS2AD223J AA C Resistor(1/10W 22KΩ ±5%) [R135]
102 VRS-TS2AD332J AA C Resistor(1/10W 3.3KΩ ±5%) [R136]
103 VRS-TS2AD751J AA C Resistor(1/10W 750Ω ±5%) [R137]
104 VRS-TS2AD244J AA C Resistor(1/10W 240KΩ ±5%) [R138]
105 VRS-TS2AD102J AA C Resistor(1/10W 1KΩ ±5%) [R139]
106 VRS-TS2AD223J AA C Resistor(1/10W 22KΩ ±5%) [R140]
107 VRS-TS2AD303J AA C Resistor(1/10W 30KΩ ±5%) [R141]
108 VRS-TS2AD332J AA C Resistor(1/10W 3.3KΩ ±5%) [R142]
109 VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R143]
110 VRS-TS2AD303J AA C Resistor(1/10W 30KΩ ±5%) [R144]
111 VRS-TS2AD102J AA C Resistor(1/10W 1KΩ ±5%) [R145]
112 VRS-TS2AD102J AA C Resistor(1/10W 1KΩ ±5%) [R147]
113 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R148]
114 VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R149]
115 VRS-TS2AD104J AA C Resistor(1/10W 100KΩ ±5%) [R152]
116 VRS-TS2AD104J AA C Resistor(1/10W 100KΩ ±5%) [R153]
117 VHDS1ZB60//-1 AC B Diode bridge(S1ZB60) [REC1]
!
118 RTRNI2165XHZZ AG N B Transformer [T1]
!
119 VHVDSS301L/-U AF B Varistor(DSS-301L) [VA1]
120 VHVSIOVS05K60 N B Varistor(SIOV-S05K60T) [VA2]
121 VHEBZX79B20/A AC B Zener diode(BZX79B20V) [ZD1]
122 VHEBZX79B6V8A N B Zener diode(BZX79B6V8) [ZD2]
123 VHEBZX79B20/A AC B Zener diode(BZX79B20V) [ZD3]
