Sharp UX-40 Service Manual

NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
UX-40DE
FO-50DE
– 7 –
[7] Control PWB unit
1 UBATL2046SCZZ AK B Battery(CR2032T34) [BAT1]
2 VCEAGA1HW106M AA C Capacitor(50WV 10µF) [C1]
3 VCEAGA1HW106M AA C Capacitor(50WV 10µF) [C2]
4 VCEAGA1EW476M AA C Capacitor(25WV 47µF) [C3]
5 VCEAGA1EW476M AA C Capacitor(25WV 47µF) [C4]
6 VCEAGA1HW226M AB C Capacitor(50WV 22µF) [C5]
7 VCEAGA1EW476M AA C Capacitor(25WV 47µF) [C6]
8 VCEAGA1HW106M AA C Capacitor(50WV 10µF) [C7]
9 VCEAGA1HW107M AA C Capacitor(50WV 100µF) [C8]
10 VCEAGA1EW476M AA C Capacitor(25WV 47µF) [C9]
11 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C100]
12 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C101]
13 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C102]
14 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C103]
15 VCCCTV1HH100D AA C Capacitor(50WV 10PF) [C104]
16 VCCCTV1HH120J AA C Capacitor(50WV 12PF) [C105]
17 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C106]
18 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C107]
19 VCKYTV1HB103K AB C Capacitor(50WV 0.01µF) [C108]
20 VCKYTV1EF104Z AA C Capacitor(25WV 0.1µF) [C110]
21 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C111]
22 VCKYTV1EF104Z AA C Capacitor(25WV 0.1µF) [C112]
23 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C113]
24 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C114]
25 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C115]
26 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C116]
27 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C117]
28 VCCCTV1HH680J AA C Capacitor(50WV 68PF) [C118]
29 VCCCTV1HH680J AA C Capacitor(50WV 68PF) [C119]
30 VCKYTV1HB222K AA C Capacitor(50WV 2200PF) [C120]
31 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C121]
32 VCKYTV1HB222K AA C Capacitor(50WV 2200PF) [C122]
33 VCKYTV1EF104Z AA C Capacitor(25WV 0.1µF) [C123]
34 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C124]
35 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C125]
36 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C126]
37 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C127]
38 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C128]
39 VCKYTV1EF104Z AA C Capacitor(25WV 0.1µF) [C129]
40 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C130]
41 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C131]
42 VCKYTV1EF104Z AA C Capacitor(25WV 0.1µF) [C132]
43 VCCCTV1HH220J AA C Capacitor(50WV 22PF) [C133]
44 VCCCTV1HH220J AA C Capacitor(50WV 22PF) [C134]
45 VCKYTV1EF104Z AA C Capacitor(25WV 0.1µF) [C135]
46 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C136]
47 VCKYTV1HF104Z AA C Capacitor(50WV 0.1µF) [C137]
48 VCKYTV1HB222K AA C Capacitor(50WV 2200PF) [C138]
49 VCKYTV1EF104Z AA C Capacitor(25WV 0.1µF) [C140]
50 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C142]
51 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C143]
52 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C144]
53 VCKYTV1EF104Z AA C Capacitor(25WV 0.1µF) [C145]
54 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C146]
55 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C147]
56 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C148]
57 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C149]
58 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C150]
59 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C151]
60 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C152]
61 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C153]
62 VCCCTV1HH220J AA C Capacitor(50WV 22PF) [C154]
63 VCCCTV1HH220J AA C Capacitor(50WV 22PF) [C155]
64 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C156]
65 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C157]
66 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C159]
67 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C160]
68 VCKYTV1EB104K AA C Capacitor(25WV 0.1µF) [C163]
69 VCKYTV1EF104Z AA C Capacitor(25WV 0.1µF) [C164]
70 VCKYTV1EF104Z AA C Capacitor(25WV 0.1µF) [C165]
71 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C166]
72 VCKYTV1EF104Z AA C Capacitor(25WV 0.1µF) [C167]
73 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C168]
74 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C169]
75 VCKYTV1HB222K AA C Capacitor(50WV 2200PF) [C170]
76 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C171]
77 VCKYTV1EF104Z AA C Capacitor(25WV 0.1µF) [C172]
78 VCCCTV1HH220J AA C Capacitor(50WV 22PF) [C173]
79 VCCCTV1HH180J AA C Capacitor(50WV 18PF) [C174]
80 VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C175]
