Sharp XV-Z12000 Service Manual

3
XV-Z12000
Specifications
Projector
XV-Z12000
NTSC 3.58/NTSC 4.43/PAL/PAL-M/PAL-N/PAL 60/SECAM
DTV480I/DTV480P/DTV720P/DTV1080I
DLP chip, RGB optical shutter method
Panel size: 0.8"
Display method: Single Panel Digital Micromirror Device (DMD™) by Texas Instruments
Drive method: Digital Light Processing (DLP™)
No. of dots: 921,600 dots (1,280 [H] X 720 [V])
1—1.35X zoom lens, F2.5—8, f = 32.5—44.0 mm
270 W SHP lamp
4-pin Mini
DIN connector (
INPUT 3)
Y (lumin
ance signal): 1.
0 Vp-p, sync neg
ative, 75
Ω termina
ted
C (chr
ominance signal): Burst 0.286 Vp-p, 75
Ω termi
nated
RCA Co
nnector (INPUT 1, 2)
Y: 1.0 Vp-p, sync negative, 75 Ω terminated
P
B : 0.7 Vp-p, 75 Ω terminated
P
R : 0.7 Vp-p, 75 Ω terminated
520 TV lines (NTSC 3.58 input), 750 TV lines (DTV 720P input)
DVI-I terminal: (INPUT 5)/RCA connector: INPUT 1/2
<Digital>
Input impedance 50 Ω
Input level 250-1000mV
<Analog>
Input
Impedance 75
Ω
Input level
0.7Vp-p
<Synchronization signal>
• Separate sync / Composite sync
Input level TTL level
Input impedance 1K Ω
• Green on sync
Input level (Synchronizing input) 0.286Vp-p
Input Impedance 75 Ω
RCA Connector: VIDEO (INPUT 4), composite video, 1.0 Vp-p, sync negative, 75 Ω
terminated
9-pin D-sub connector (RS-232C Port)
12—120 MHz
43—100 Hz
15—81 kHz
AC 100—240 V
3.7 A (When using AC100V)
50/60 Hz
365 W
About 0.1 W (When using 100 V)
1,400 BTU/hour
41°F to 95°F (+5°C to +35°C)
—4°F to 140°F (—20°C to +60°C)
Plastic
38 kHz
18
11
/ 16 " X 7" X 15
49
/ 50 " (475 (W) X 178 (H) X 406 (D) mm) (main body only)
18
11
/ 16 " X 7" X 19
1
/ 2 " (475 (W) X 178 (H) X 496 (D) mm) (including terminal cover)
20.7 lbs. (9.4 kg)
Product type
Model
Video system
Display method
DLP panel
Lens
Projection lamp
S-video in
put signal
Comp
onent input signal
Horizontal resolution
RGB input signal
Video input signal
Computer control signal
Pixel clock
Vertical frequency
Horizontal frequency
Rated voltage
Input current
Rated frequency
Power consumption (normal)
Power consumption(standby)
Heat dissipation
Operating temperature
Storage temperature
Cabinet
I/R carrier frequency
Dimensions (approx.)
Weight (approx.)
Supplied accessories
Replacement parts
This SHARP projector uses a DMD Chip. This very sophis-
ticated panel contains 921,600 pixels. As with any high tech-
nology
electronic equipment such as large screen TVs, video
systems and video cameras, there are certain acceptable
tolerances that the equipment must conform to.
This unit has some inactive pixels within acceptable toler-
ances which may result in inactive dots on the picture screen.
Th
is will not affect the picture quality or the life expectancy
of the unit.
Specifications are subject to change without notice.
Remote control, Two AA size batteries, Power cord (9'10", 3.0 m), DVI to 15-pin D-Sub
adaptor, 21pin RCA conversion adaptor, Video cable, Terminal cover, Lens cap (attached),
SharpVision Manager Software CD-ROM, Projector operation manual, Sharp Vision Manager
operation manual
Lamp unit (Lamp/cage module) (BQC-XVZ100005), Remote control (RRMCGA216WJSA), AA
size batteries , Power cord for U.S.:CACCDA024DE01, Power cord for Europe (without U.K)
and Korea:QACCVA011WJPZ, Power cord for U.K., Hong Kong and Singapore
:QACCBA036WJPZ, Power cord for Australia and New Zealand:QACCLA018WJPZ
, DVI to
15-pin D-Sub adaptor (QCNWGA010WJPZ : except for U.S.), 21pin RCA conversion adaptor
(QSOCZ0361CEZZ : for Europe without U.K. and Korea), Video cable (QCNWGA001WJZZ :
except for U.S)
, Terminal cover (CCOVA1985CE03), Lens cap (PCAPH1056CESA),
SharpVision Manager Software CD-ROM (UDSKAA040WJZZ), Projector operation manual for
U.S.:TiNS-A970WJZZ, Projector operation manual for 7 European language:TiNS-A972WJZZ,
Projector operation manual for Chinese, Korean and Arabic language :TiNS-A973WJZZ,
SharpVision Manager operation manual (TiNS-B097WJZZ)
