Sharp XV-Z12000 Service Manual

181
XV-Z12000
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
DUNTKC175DE01
LED UNIT
DIODES
D2202 RH-PX0445CEZZY J LED RED & BLUE AM
D2203 RH-PX0445CEZZY J LED RED & BLUE AM
D2204 RH-PX0196TAZZ J LED RED AC
CAPACITOR
C2204 VCKYCY1CB104K J 0.1 16V Ceramic AB
RESISTORS
R2213 VRS-TV1JD182J J 1.8k 1/10W Metal Oxide AA
R2214 VRS-TV1JD472J J 4.7k 1/10W Metal Oxide AA
R2215 VRS-TV1JD102J J 1.0k 1/10W Metal Oxide AA
R2216 VRS-TV1JD102J J 1.0k 1/10W Metal Oxide AA
R2217 VRS-TV1JD472J J 4.7k 1/10W Metal Oxide AA
MISCELLANEOUS PART
P2450 QPLGN0758REZZY J Plug, 7pin(RE) AC
DUNTKC176DE01
IRIS UNIT
INTEGRATED CIRCUITS
IC2101 VHiPQ1M505M-1Y J Integrated Circuits AD
IC2104 VHiM62320FP-1Y J M62320FP AH
IC2105 VHiLB1831M/-1Y J LB1831M AL
DIODE
D2101 VHDHSU119//-1Y J HSU119 AB
CAPACITORS
C2101 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2102 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C2103 VCEAPF1CW107MY J 100 16V Electrolytic AC
C2109 VCKYCY1EB104KY J 0.1 25V Ceramic AB
RESISTORS
R2101 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2103 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2104 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2106 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R2108 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R2110 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
P2101 QPLGN0558REZZY J Plug, 5pin AE
P2103 QPLGN0358REZZY J Plug, 3pin AD
P2104 QPLGN0258REZZY J Plug, 2pin AD
DUNTKB474FE03
FORMATTER UNIT
INTEGRATED CIRCUITS
IC9001 VHiVCX16374-1Y J TC74VCX16374FT AL
IC9002 VHiVCX16374-1Y J TC74VCX16374FT AL
IC9003 VHi7SA34FU+-1Y J TC7SA34FU AD
IC9004 VHiPQ05VY3H-1Y J PQ05VY3H3ZP AK
IC9005 VHiTA75S393-1Y J TA75S393F AD
IC9101 VHiDDP1010+-1Q J 2503227-001 BX
IC9102 RH-iXA826WJZZQ J IC AQ
IC9201 VHiPQ018EZ5-1Y J PQ018EZ5MZP AF
IC9202 VHiTCDCR83D-1Y J CDCR83DBQR AR
IC9203 VHiK4R271T8-1Q J K4R271669D-TCS BC
IC9301 RH-iXA384WJZZQ J 2503253-0002 BP
IC9401 VHiSH6742C+-1Q J SH6742CFA0PAG BD
IC9402 VHiLVC1G07C-1Y J SN74LVC1G07 AE
IC9403 VHiPQ1L503M-1Y J PQ1L503M2SP AD
TRANSISTORS
Q9401 VSTPC8209++-1Y J TPC8209 AE
Q9402 VSTPC8209++-1Y J TPC8209 AE
Q9403 VSTPC8209++-1Y J TPC8209 AE
DIODES
D9001 VHDMi1A3///2EY J MI1A3 AC
D9002 RH-EX1243CEZZY J Zener Diode AB
D9003 RH-EX1232CEZZY J Zener Diode AB
D9201 VHDMI1A3///2EY J MI1A3 AC
D9301 VHDSFPB56//2EY J SFPB56 AC
D9401 VHDBAV99RW+-1Y J BAV99RW AC
D9402 VHDSFPA73//2EY J SFPA73 AD
D9404 VHDBAT54SWT-1Y J BAT54SWT AC
D9405 VHDBAT54SWT-1Y J BAT54SWT AC
D9406 VHDBAT54SWT-1Y J BAT54SWT AC
D9407 VHDBAT54SWT-1Y J BAT54SWT AC
D9408 VHDBAT54SWT-1Y J BAT54SWT AC
D9409 VHDHSU119//-1Y J HSU119 AB
PACKAGED CIRCUIT
X9101 RCRUAA041WJZZY J Crystal AN
COILS AND FILTERS
FL9001 RFILN0533CEZZY J Filter AC
FL9002 RFILN0533CEZZY J Filter AC
FL9003 RFILN0533CEZZY J Filter AC
L9301 VPCLN220MR77NY J Peaking 22µHAB
L9302 VPCLN220MR77NY J Peaking 22µHAB
L9303 VPCLN220MR77NY J Peaking 22µHAB
L9304 VPCLN220MR77NY J Peaking 22µHAB
CAPACITORS
C9001 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9002 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9003 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9004 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9005 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9006 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9007 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9008 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9009 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9010 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9011 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9012 VCKYCY1AB105KY J 1 10V Ceramic AB
C9013 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9020 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9021 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9022 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9023 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9024 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9025 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9026 VCEASH1CN107MY J 100 16V Electrolytic AC
C9027 VCEASH1CN107MY J 100 16V Electrolytic AC
C9101 VCKYCY1EB104KY J 0.1 25V Ceramic AB
