Sharp XV-Z12000 Service Manual

180
XV-Z12000
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
DUNTKC172DE01
KEY UNIT
CAPACITOR
C2202 VCKYCY1CB104KY J 0.1 16V Ceramic AB
RESISTORS
R2201 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R2202 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R2203 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R2204 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R2205 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R2206 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R2207 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2210 VRS-CH1JF103JY J 10k 1/16W Metal Oxide AA
R2211 VRS-CH1JF102JY J 1k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
SW2201QSW-K0065GEZZY J Switch, Power AD
SW2202QSW-K0065GEZZY J Switch, Cursor ' AD
SW2203QSW-K0065GEZZY J Switch, Cursor " AD
SW2204QSW-K0065GEZZY J Switch, Input 1,2,3 AD
SW2205QSW-K0065GEZZY J Switch, Menu AD
SW2206QSW-K0065GEZZY J Switch, Cursor | AD
SW2207QSW-K0065GEZZY J Switch, Cursor \ AD
SW2208QSW-K0065GEZZY J Switch, Enter AD
SW2209QSW-K0065GEZZY J Switch, Undo AD
SW2210QSW-K0065GEZZY J Switch, Power Off AD
SW2211 QSW-K0065GEZZY J Switch, Resize AD
CN2202 QPLGN1358REZZY J Plug, 13pin(KY) AD
P2814 QPLGN0364TAZZY J Plug, 3pin(RA) AC
P2815 QPLGN0763TAZZY J Plug, 7pin AD
DUNTKC174DE01
R/C REAR UNIT
CAPACITORS
C2404 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2406 VCEAPF0JW107MY J 100 6.3V Electrolytic AC
RESISTORS
R2403 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R2404 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
P2402 QPLGN0364TAZZY J Plug, 3pin(RA) AC
RMC2402 RRMCU0237CEZZ J R/C Receiver AF
DUNTKC173DE01
R/C FRONT UNIT
CAPACITORS
C2401 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2403 VCEAPF0JW107MY J 100 6.3V Electrolytic AC
RESISTORS
R2401 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R2402 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
P2401 QPLGN0364TAZZY J Plug, 3pin(RC) AC
RMC2401 RRMCU0239CEZZ J R/C Receiver AG
DUNTKC171DE01
MAIN UNIT(Continued)
FB2811 RBLN-0058TAZZY J Ferrite Bead AC
FB2812 RBLN-0058TAZZY J Ferrite Bead AC
FB2813 RBLN-0059CEZZY J Ferrite Bead AB
FB2814 RBLN-0064TAZZY J Ferrite Bead AB
FB2815 RBLN-0064TAZZY J Ferrite Bead AB
FB2816 RBLN-0064TAZZY J Ferrite Bead AB
FB2817 RBLN-0064TAZZY J Ferrite Bead AB
FB2818 RBLN-0064TAZZY J Ferrite Bead AB
FB2819 RBLN-0064TAZZY J Ferrite Bead AB
FB2820 RBLN-0064TAZZY J Ferrite Bead AB
FB2821 RBLN-0064TAZZY J Ferrite Bead AB
FB2822 RBLN-0062CEZZY J Ferrite Bead AC
FB2823 RBLN-0058TAZZY J Ferrite Bead AC
FB2824 RBLN-0060TAZZY J Ferrite Bead AB
FB2825 RBLN-0060TAZZY J Ferrite Bead AB
FB2828 RBLN-0062CEZZY J Ferrite Bead AC
FB2829 RBLN-0058TAZZY J Ferrite Bead AC
FB2830 RBLN-0058TAZZY J Ferrite Bead AC
FB2831 RBLN-0058TAZZY J Ferrite Bead AC
FB2833 RBLN-0058TAZZY J Ferrite Bead AC
FB2834 RBLN-0059CEZZY J Ferrite Bead AB
FB2835 RBLN-0058TAZZY J Ferrite Bead AC
FB2836 RBLN-0058TAZZY J Ferrite Bead AC
FB2837 RBLN-0058TAZZY J Ferrite Bead AC
FB2841 RBLN-0058TAZZY J Ferrite Bead AC
FB2843 RBLN-0090CEZZY J Ferrite Bead AD
FB2844 RBLN-0090CEZZY J Ferrite Bead AD
FB2845 RBLN-0084CEZZY J Ferrite Bead AC
FB2846 RBLN-0084CEZZY J Ferrite Bead AC
FB2847 RBLN-0090CEZZY J Ferrite Bead AD
FB2848 RBLN-0090CEZZY J Ferrite Bead AD
FB2849 RBLN-0090CEZZY J Ferrite Bead AD
FB2850 RBLN-0090CEZZY J Ferrite Bead AD
FB3501 RBLN-0059CEZZY J Ferrite Bead AB
FB3502 RBLN-0059CEZZY J Ferrite Bead AB
FB3507 RBLN-0064TAZZY J Ferrite Bead AB
J2501 QJAKLA001WJZZ J Jack, Component 1 AN
J2503 QJAKHA002WJZZ J Jack, Component 2 AM
J2505 QJAKZ1053CEZZ J Jack, S Video AG
J2801 QJAKA0022CEZZ J Jack, Wired R/C AC
J2802 QJAKE0071CEZZ J DC 12V Out AD
P2001 QPLGN1358REZZY J Plug, 13pin(KEY) AD
P2801 QPLGN0540FJZZY J Plug, 2pin AD
P2802 QPLGN0539FJZZY J Plug, 3pin(TB) AD
P2804 QPLGN0176FJZZY J Plug, 4pin(FA) AD
P2805 QPLGN0541FJZZY J Plug, 4pin(FB) AD
P2806 QPLGN0540FJZZY J Plug, 3pin(FC) AD
P2807 QPLGN0565FJZZY J Plug, 3pin(FD) AD
P2809 QPLGN0464TAZZY J Plug, 4pin(CA) AC
P2810 QPLGN0565FJZZY J Plug, 3pin(RC) AD
P2811 QPLGN0550FJZZY J Plug, 13pin(EA) AF
P2812 QPLGN0547FJZZY J Plug, 10pin(EB) AE
P2813 QPLGN0547FJZZY J Plug, 10pin(J2) AE
P3580 QCNCM6013CEZZY J Plug, 31pin AL
P3581 QCNCM6013CEZZY J Plug, 31pin AL
P3582 QCNCM6013CEZZY J Plug, 31pin AL
SC2801 QSOCN0437FJZZ J Connector, RS-232C AM
