Sharp XV-Z12000 Service Manual

175
XV-Z12000
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
DUNTKC171DE01
MAIN UNIT
ERSATZTEILLISTE
AUSTAUSCH VON TEILEN
Ersatzteile, die besondere Sicherheitseigenschften haben, sind in
dieser Anleitung markiert. Elektrische Komponenten mit solchen
Eigenshaften sind in den Ersatzteil durch "å" gekenn-zeichnet.
Der Gebrauch von Ersatzteilen, die nicht deselben Sicherheits-
eigenschaften haben wie die vom Hersteller empfohlenen ud in der
Bedienungsanleitung angegebenen, können zur Ursache von
Blitzeinschlägen, Bränden und anderen Gefahren werden.
"WIE MAN ERSATSTEILE BESTELLT"
Damit Ihre Bestellung promt und korrekt ausgeführt wird, geben Sie
bitte folgende Informationen.
1. MODELL NR. 2. REF. NR.
3. ERSATZTEIL NR. 4. BESCHREIBUNG
5. KODE 6. QUANTITÄT
PARTS LIST
PARTS REPLACEMENT
Parts marked with "å" are important for maintaining the safety of
the set. Be sure to replace these parts with specified ones for main-
taining the safety and performance of the set.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
5. CODE 6. QUANTITY
in USA: Contact your nearest SHARP Parts Distributor.
For location of SHARP Parts Distributor,
Please call Toll-Free; 1-800-BE-SHARP
in CANADA: Contact SHARP Electronics of Canada Limited
Phone (416) 890-2100.
★ MARK: SPARE PARTS-DELIVERY SECTION
★ MARKIERUNG : ERSATZTEILE-LIEFERUNG
DUNTKC171DE01 - Main Unit —
DUNTKC172DE01 - Key Unit —
DUNTKC173DE01 - Front R/C Unit —
DUNTKC174DE01 - Rear R/C Unit —
DUNTKC175DE01 - LED Unit —
DUNTKC176DE01 - IRIS DRIVE Unit —
DUNTKB474FE03 - Formatter Unit —
RDENCA055WJZZ - Power Unit —
CPCi-A008CE01 - PC I/F Unit —
RDENCA027WJZZ - Ballast Unit CA
(Unit Replacement Item)
INTEGRATED CIRCUITS
IC2001 VHiMAX3224E-1Y J MAX3224ECAP AU
IC2002 VHiMM1573DN-1Y J MM1573DNRE AD
IC2003 VHiSN2G53CT-1Y J SN74AHC2G53HDC AE
IC2004 VHiSN2G32CT-1Y J SN74AHC2G32HDC AE
IC2005 RH-iXA825WJN1Q J IC BD
IC2006 VHiPST600IM-1Y J IC-PST600IMT AE
IC3506 VHiPST600IM-1Y J IC-PST600IMT AE
IC2007 VHiS24C02A/-1Y J S-24C02AFJ-TB AK
IC2501 VHiLV4053AT-1Y J SN74LV4053APWR AE
IC2506 VHiLV4053AT-1Y J SN74LV4053APWR AE
IC2505 VHiMM1519XQ-1Q J MM1519XQ AW
IC2508 VHiTL712CPS-1Y J TL712CPS AH
IC2511 VHiTL712CPS-1Y J TL712CPS AH
IC2512 VHiTL712CPS-1Y J TL712CPS AH
IC2513 VHiTL712CPS-1Y J TL712CPS AH
IC2509 VHiLV125AT+-1Y J SN74LV125APWR AE
IC2510 VHiNJM2903V-1Y J NJM2903V AD
IC2514 VHiTHC4538T-1Y J TC74HC4538AFT AL
IC2515 VHiT7SET08U-1Y J TC7SET08FU AD
IC2811 VHiT7SET08U-1Y J TC7SET08FU AD
IC2812 VHiT7SET08U-1Y J TC7SET08FU AD
IC2814 VHiT7SET08U-1Y J TC7SET08FU AD
IC2815 VHiT7SET08U-1Y J TC7SET08FU AD
IC2816 VHiT7SET08U-1Y J TC7SET08FU AD
IC2805 VHiPQ09DZ1U-1Y J PQ09DZ1U AG
IC2806 VHiPQ30RV211E J PQ30RV21 AK
IC2807 VHiPQ050DZ1-1Y J PQ050DZ01Z AE
IC3580 VHiPQ050DZ1-1Y J PQ050DZ01Z AE
IC2808 VHiPQ20VB1E-1 J PQ20VB1E AH
IC2809 VHiPQ033DZ1-1Y J PQ033DZ01ZP AE
IC2817 VHiPQ05VY3H-1Y J PQ05VY3H3ZP AK
IC2818 VHiPQ20VZ11-1Y J PQ20VZ11 AG
IC3501 VHiTK15420/-1Y J TK15420MTL AG
IC3504 VHiPD64082/-1S J UPD64082GF-3BA BC
IC3505 RH-iX3420CEZZY J MSM5416258B-28 AT
IC3507 VHiM52055FP-1Y J M52055FP AH
TRANSISTORS
Q2001 VSHN2A01FU/-1Y J HN2A01FU AC
Q2002 VSRN4982///-1Y J RN4982 AB
Q2004 VSRN4904///-1Y J RN4904 AB
